INSTALLATION INSTRUCTIONS
PARTS LIST:
Qty
Description
Headache Rack
1
1
Driver/Left Mounting Bracket
1
Passenger/Right Mounting Bracket
4
12mm x 40mm Hex Bolts
Driver/left side
Mounting Bracket
1999-2012 FORD F250, SUPER DUTY
(LARGER MULTI FIT BLACK) PART # 111001
Headache Rack
Qty
Description
4
12mm x 50mm Hex Bolts
8
12mm Lock Washers
16
12mm Flat Washers
8
12mm Hex Nuts
Passenger/right side
Mounting Bracket
Advertisement
Related Manuals for Aries Offroad 111001
Summary of Contents for Aries Offroad 111001
-
Page 1: Installation Instructions
INSTALLATION INSTRUCTIONS 1999-2012 FORD F250, SUPER DUTY (LARGER MULTI FIT BLACK) PART # 111001 PARTS LIST: Description Description Headache Rack 12mm x 50mm Hex Bolts Driver/Left Mounting Bracket 12mm Lock Washers Passenger/Right Mounting Bracket 12mm Flat Washers 12mm x 40mm Hex Bolts... - Page 2 PROCEDURE: 1. REMOVE CONTENTS FROM BOX. VERIFY ALL PARTS ARE PRESENT. READ INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION. 2. From the list above select the Driver/Left side mounting bracket and secure to the bottom of the outside mount of the Headache rack with (2) 12mm x 40mm Hex Bolts, (4) 12mm Flat Washer, (2) 12mm Lock Washers and (2) 12mm nuts, repeat this process for Passenger/right side mounting bracket, (Fig 1) shows Driver/left side bracket attached to Headache rack, Snug but do not tighten hardware at this time.
