Convertible Top Installation Guide
2000-2008 Honda S2000 Roadster
Notice
Th is document is intended for experienced automotive technicians or professional installers. Although many car owners have
successfuly installed their own convertible tops, we do recommend you utilize the services of a professional Trim & Upholstery
Shop for best results.
Tools Required
•
Phillip and fl at screwdrivers
•
Sockets: 10, 12 and 14mm
•
2" putty knife
•
Clip removal tool
•
6" straight pick
•
Rubber mallet
•
3' hanger wire
•
1/2" double-tape
•
Rivet gun with 1/4" 12mm rivets
•
Needle nose pliers
•
Drill with 5/32" drill bit
Advertisement
Related Manuals for Sierra 10-19-S20-011
Summary of Contents for Sierra 10-19-S20-011
- Page 1 Convertible Top Installation Guide 2000-2008 Honda S2000 Roadster Notice Th is document is intended for experienced automotive technicians or professional installers. Although many car owners have successfuly installed their own convertible tops, we do recommend you utilize the services of a professional Trim & Upholstery Shop for best results.
-
Page 2: Top Removal
2000 - 2008 Honda S2000 Roadster Convertible Top Installation Guide TOP REMOVAL Retract frame to open position, use 14mm socket to remove both seats from vehicle for accessibility. Remove phillip screws to release both rear wall trim covers from vehicle. - Page 3 2000 - 2008 Honda S2000 Roadster Convertible Top Installation Guide Remove phillip screws and unclip to release both door step-in trim covers from vehicle. Remove phillip screws to release both quarter panels from vehicle.
- Page 4 2000 - 2008 Honda S2000 Roadster Convertible Top Installation Guide Remove phillip screws to release both upper quarter trim covers from frame. Remove phillip screws to release both side horizontal rubber weather seals from frame.
- Page 5 2000 - 2008 Honda S2000 Roadster Convertible Top Installation Guide Remove phillip screws to detach horizontal seal metal retainers from frame. Remove phillip screws across header, release metal retainer and detach Top front edge from frame.
- Page 6 2000 - 2008 Honda S2000 Roadster Convertible Top Installation Guide Remove phillip screws and unclip to release vertical weather seals from frame. Remove phillip screws to release vertical seal metal channel brackets from frame.
- Page 7 2000 - 2008 Honda S2000 Roadster Convertible Top Installation Guide Remove phillip screws to detach wind screen assembly from vehicle to gain accessibility. Retract frame to midway position and remove screws to detach vertical seal retainers.
- Page 8 2000 - 2008 Honda S2000 Roadster Convertible Top Installation Guide Carefully cut or drill rivet heads to release Top quarter attachments from frame. Retract frame to closed position. Use a straight pick and unlock clips to remove Top well trim panels.
- Page 9 2000 - 2008 Honda S2000 Roadster Convertible Top Installation Guide Retract frame to midway position, remove both vertical and fl at Top well trim panels from vehicle. Remove lock clip and phillip screws to release both side Top well trim panels from vehicle.
- Page 10 2000 - 2008 Honda S2000 Roadster Convertible Top Installation Guide Using a 12mm socket, remove rear base bolt nuts to release support metal brackets from vehicle. 2002-06 models, support straps secured to 4th bow and base is attached from inside of rain rail. 2000-01 models with retrofi t to glass window, follow supplied instructions with replacement Top.
- Page 11 2000 - 2008 Honda S2000 Roadster Convertible Top Installation Guide Retract frame to open position, remove both end rain rail lock clips to release Top from vehicle. Retract frame to closed position and start to remove Top from base attachment.
- Page 12 2000 - 2008 Honda S2000 Roadster Convertible Top Installation Guide Use a putty knife and carefully pry open cross bow to release Top/liner sleeve. Using needle nose pliers, pry open spring loop attachment to release tension cables.
- Page 13 2000 - 2008 Honda S2000 Roadster Convertible Top Installation Guide Pull-out tension cables and remove Top from vehicle. Drill rivets to remove and re-use rain rail on new replacement Top.
-
Page 14: Top Installation
2000 - 2008 Honda S2000 Roadster Convertible Top Installation Guide If necessary, replace worn elastic straps before installing new top. TOP INSTALLATION Locate rain rail and Top base retainer to center position and start riveting to either direction. - Page 15 2000 - 2008 Honda S2000 Roadster Convertible Top Installation Guide Carefully apply super glue onto extended Top binding and fold inner side additional for support. Attach Top and headliner velcro sleeves together fi rst, then insert both into 3rd cross bow channel.
- Page 16 2000 - 2008 Honda S2000 Roadster Convertible Top Installation Guide Using a rubber mallet, carefully tap across bow to ensure sleeve fi t into guided channel. Stretch Top forward and attach front sleeve listing to 2nd cross “fl oating” bow.
- Page 17 2000 - 2008 Honda S2000 Roadster Convertible Top Installation Guide Use 3’ hanger wire to connect tension cables to Top, by inserting them thru side pocketed sleeves. Retract frame to midway position and attach Top front edge to frame header for positioning.
- Page 18 2000 - 2008 Honda S2000 Roadster Convertible Top Installation Guide Retract frame to closed position, connect tension cables to relief spring and secure springs to frame. Connect Top at rear, attach lock clips and re-attach support brackets by “hand tightening” bolts fi rst.
- Page 19 2000 - 2008 Honda S2000 Roadster Convertible Top Installation Guide Retract frame to midway position, attach quarter pockets into frame and secure with rivets to hold. Slightly retract frame to lower position and install phillip screws to secure quarter pockets to frame.
- Page 20 2000 - 2008 Honda S2000 Roadster Convertible Top Installation Guide Retract frame to closed position, with a 14mm socket tighten base bolts to secure Top to vehicle. Retract frame to midway position, with phillips secure metal retainer and Top to frame header.
- Page 21 2000 - 2008 Honda S2000 Roadster Convertible Top Installation Guide Apply ½” double-tape to outer sides of header and attach Top fl aps to hold. Use phillip screws to secure horizontal seal metal retainers to frame and attach rubber seals.
- Page 22 2000 - 2008 Honda S2000 Roadster Convertible Top Installation Guide Slightly retract frame to lower position, and attach seal support brackets to frame. Use phillip screws to secure vertical seal metal retainers to frame.
- Page 23 2000 - 2008 Honda S2000 Roadster Convertible Top Installation Guide Attach vertical rubber seal clips fi rst, then force into channel by using a 2” putty knife to secure. Retract frame to close position, re-attach Top well side trim panels using lock clips and phillip screws.
- Page 24 2000 - 2008 Honda S2000 Roadster Convertible Top Installation Guide Using phillip screws, attach both upper quarter trim covers back to vehicle. Using phillip screws, secure quarter panels back to vehicle.
- Page 25 2000 - 2008 Honda S2000 Roadster Convertible Top Installation Guide Attach both step-in trim covers by clips and phillip screws. Using phillip screws, attach both rear wall trim covers.
- Page 26 2000 - 2008 Honda S2000 Roadster Convertible Top Installation Guide Carefully route defrost wire thru pocketed sleeves and connect plugs to glass pins. Retract frame to midway position, install lower and vertical well trim panels into compartment.
- Page 27 2000 - 2008 Honda S2000 Roadster Convertible Top Installation Guide Use lock clips and phillip screws, secure lower and vertical well trim panels to vehicle. Use phillip screws to re-attach wind screen assembly to vehicle.
- Page 28 2000 - 2008 Honda S2000 Roadster Convertible Top Installation Guide Use 14mm socket to re-install seats back into vehicle.
