Bearing Type
Ball Bearings
*
Material
Impeller & Frame : Plastic(UL 94V-0)
*
Lead Wires :
UL 1061 AWG #26 OR Equivalent
Red Wire Positive(+)
Black Wire Negative(-)
*
Weight : 21g (0.74 OZ)
MODEL
PART NO.
REV
FUNCTION
GFB0412SHG
-A -R00 / -F00
* Function type is optional.
* The max. air flow and the speed are measured in free air ; max. air pressure is measured at zero air flow.
* Noise is measured in anechoic chamber in free air, one meter from intake side.
* All readings are typical values at rated voltage.
* Specifications are subject to change without notice.
GFB
DIMENSIONS DRAWING
P & Q CURVE
Operating
Rated
Input
Voltage
Voltage
Current
Range
VDC
VDC
Amp
12
4.0 to 13.2
1.10
40 x 40 x 48 MM SERIES
(AT RATED VOLTAGE)
Input
Speed
Power
(Front /Rear)
3
Watt
R.P.M.
M /min
13.20
12800/10200
0.670
71
MOUNTING PANEL CUTOUT
OUTLET SIDE
INLET SIDE
Maximum
Maximum
Air Flow
Air Pressure
CFM
mmH O
IN H O
2
23.66
32.31
1.27
http://www.deltaww.com
Noise
dB-A
2
59.0
