- Page 1 WECO Reverse Osmosis Drinking Water Filter System Manual MINY Series wecofilters.com Water Engineering Corporation California, U.S.A 1 (888) 675-5187 sales@wecofilters.com...
- Page 2 6 months. It is advised to change them on time to avoid any damages to the RO membrane filters. It is advised to use WECO replacement. filters. Using ‘non-WECO’ and poor quality filters may clog the MINY-SET4 RO system and will also damage the membrane.
- Page 3 © Water Engineering Corporation Carbon Carbon Sediment Pre-Filter Pre-Filter Pre-Filter Water supply adapter valve Carbon Block Filters WECO FilterMembrane Undersink Cold Water Angle Drain Saddle Post Carbon Filter Stop Valve RO Water Pressurized Drinking Water RO Faucet Alkaline Filter (optional) Storage Tank...
-
Page 4: Installation Instructions
MINY Manual INSTALLATION INSTRUCTIONS Tapping into the cold water line (Using the water supply adapter model EZROADP-EZ14) RO Ball Valve NOTE: The drinking water system must be connected to the COLD water supply only. 1. Turn off the cold water supply to the sink faucet by locating the Round or oblong handle on the right side of the sink cabinet and Turning clockwise until the water supply is off. -
Page 5: Mounting The Faucet
MINY Manual Mounting the faucet Your unit comes complete with a long reach faucet. NOTE: Air gap option installation instructions are available upon request. The following instructions is for non-air gap option. 1. Slide chrome cover plate and rubber gasket onto stem of faucet and place faucet onto sink with the stem going through the hole. -
Page 6: Positioning The System
MINY Manual 3. Make sure to align drain saddle to drilled hole. Attach drain clamp to drain pipe and tighten the two screws evenly. (Fig. # 7) NOTE: The center hole on the sponge must be removed. 4. Connect the Black tubing to the drain clamp. Fig. -
Page 7: Start-Up Procedure
MINY Manual START-UP PROCEDURE 1. Check to see all connections are made 2. Check that the pre-filter and pre-carbon sumps are secure using the housing wrench provided. 3. Slowly turn on the water by turning the needle valve counterclockwise. 4. The valve handle on top of the tank should be in the open position, parallel to the valve body 5. - Page 8 MINY Manual Sediment Pre-filter: The pre-filter protects the system and should be maintained regularly, a clear housing has been provided for your convenience. The snow-white pre-Filter should be changed when the outside discolors to a cardboard brown color and before the inner surface discolors.
-
Page 9: Changing The Membrane
MINY Manual CHANGING THE PRE-FILTERS 1. Turn OFF cold water supply to RO system. Turn OFF tank’s ball-valve. Lift up RO faucet lever briefly to relief the built-up pressure inside the RO system. This will make opening the housings easier. 2. -
Page 10: Recommended System Maintenance
If the system is placed in an area prone to water damage, install a third-party leak detection and shut-off device. To properly maintain your WECO drinking water system, please use only genuine WECO water replacement filters at www.wecofilters.com... -
Page 11: Operating Specifications
MINY Manual OPERATING SPECIFICATIONS Water Pressure 50 – 75 PSI pH Range 4 – 11 Max. TDS 1000 ppm Water Temperature 40-85 °F Hardness < 2 GPG Iron < 0.25 ppm Hydrogen Sulfide Must be removed Silica < 25 ppm CONTACT US For replacements cartridges and accessories shop www.wecofilters.com... - Page 12 WECO MINY Series Reverse Osmosis Drinking Water Filter System Manual WECO wecofilters.com Water Engineering Corporation Signal Hill, CA U.S.A. 1 (888) 675-5187 sales@wecofilters.com...
