ASSEMBLY INSTRUCTION
B181571BUT/DZT/RNT-1 TWIN METAL BED
PART LIST:
A: Lsf/Rsf hb Leg
2PCS
E:Side Rail
2PCS
I: Slat Connector
32PCS
HARDWARE LIST:
1: Bolt 1/4*22mm
X 8pcs
B: Headboard
1PC
F: Center Cross Bar
1PC
2: Bolt 5/16*19mm
X 8pcs
C: Footboard
1PC
G:Center Slat
Support Leg
2PC
3: Bolt 1/4*17.5mm
X 6pcs
D:Side Rail
2PCS
H:Slat
16PCS
4: Allen Key
X 1pc
Page:1/3
Advertisement
Related Manuals for Homelegance Lexicon B181571BUT-1
Summary of Contents for Homelegance Lexicon B181571BUT-1
- Page 1 ASSEMBLY INSTRUCTION B181571BUT/DZT/RNT-1 TWIN METAL BED PART LIST: B: Headboard D:Side Rail C: Footboard A: Lsf/Rsf hb Leg 2PCS 2PCS F: Center Cross Bar H:Slat G:Center Slat E:Side Rail 16PCS Support Leg 2PCS I: Slat Connector 32PCS HARDWARE LIST: 1: Bolt 1/4*22mm 2: Bolt 5/16*19mm 3: Bolt 1/4*17.5mm 4: Allen Key...
- Page 2 N ote: Please do not tighten all bolts until the bed is assembled completely. STEP 1 STEP 2 Hardware 3: 2 pcs Hardware 3: 4 pcs STEP 3 STEP 4 Hardware 1: 4 pcs Hardware 1: 4 pcs STEP 5 Hardware 2: 8 pcs Page:2/3...
- Page 3 N ote: Please do not tighten all bolts until the bed is assembled completely. STEP 6 COMPLETED Page:3/3...
