VideoMate V220/V220F TV Box Connection

S-Video Input
6
Composite
Video Input
FM Antenna Input
(V220F only)
Power Adaptor
Line-Out to Speaker
Line-In from the Line-Out
connector of sound card
Connect to monitor by
VGA cable
Connect from TV box to
VGA card by 9-pin
Mini-DIN to 15-pin D-Sub
cable in the package
Analog TV
Cable/Antenna Input
Stereo Audio
Input (L/R)
