Delta Electronics Exhaust Fan AFB Series Specification

Bearing Type
*
Ball Bearings
Material
*
Impeller & Frame : Plastic(UL 94V-0)
Lead Wires :
*
UL 1061 AWG #26 OR Equivalent
Red Wire Positive(+)
Black Wire Negative(-)
Weight : 10.5g (0.37 OZ)
*
Rib Type Only & One Side Flange
*
MODEL
PART NO. REV. FUNCTION
AFB02505LA -A -R00 / -F00
AFB02505MA -A -R00 / -F00
AFB02512MA -A -R00 / -F00
AFB02505HA -A -R00 / -F00
AFB02512HA -A -R00 / -F00
AFB02505HHA -A -R00 / -F00
AFB02512HHA -A -R00 / -F00
* Function type is optional.
* The max. air flow and the speed are measured in free air ; max. air pressure is measured at zero air flow.
* Noise is measured in anechoic chamber in free air, one meter from intake side.
* All readings are typical values at rated voltage.
* Specifications are subject to change without notice.
AFB
DIMENSIONS DRAWING
■
P & Q CURVE
■
0.36
9.0
0.30
7.5
0.24
6.0
0.18
4.5
0.12
3.0
0.06
1.5
0 0
0 .015
0
Operating
Rated Input
Voltage
Voltage Current
Range
VDC VDC Amp
5 4.0 to 5.5 0.04
5 4.0 to 5.5 0.06
12 9.5 to 13.2 0.04
5 4.0 to 5.5 0.12
12 7.0 to 13.2 0.06
5 4.0 to 5.5 0.16
12 7.0 to 13.2 0.08
25 x 25 x 10 MM SERIES
25.0±0.5
(0.984±0.020)
20.0±0.3
(0.787±0.012)
LABEL
4-Ø2.8±0.3
(4-Ø0.110±0.012)
150.0±10.0
(5.906±0.394)
(AT RATED VOLTAGE)
AFB02505/12XA-A
HH
H
M
L
(M 3 /MIN)
.030 .045 .060 .075
(CFM)
0.6 1.2 1.8 2.4
Air Flow
Input
Speed
Power
Watt R.P.M. m
0.20 5000 0.024
0.30
7000 0.034
0.48
0.60
10000 0.052
0.72
0.80
13000 0.068
0.96
10.0±0.5
(0.394±0.020)
10.0
(0.394)
UNIT :
MOUNTING PANEL CUTOUT
■
OUTLET SIDE
20.0
(0.787)
4-Ø2.8
(4-Ø0.110)
Maximum Maximum
Air Flow Air Pressure
3 /min CFM mmH O
2
0.85 1.15
1.20 2.18
1.84 4.48
2.40 7.65
http://www.deltaww.com
mm
(INCH)
INLET SIDE
20.0
(0.787)
4-Ø2.8
(4-Ø0.110)
mm
UNIT :
(INCH)
Noise
IN H O dB-A
2
0.045 18.0
0.085 20.0
0.176 23.5
0.300 28.0
