- Page 1 BLACK MODULAR GRILLE GUARD FOR HONDA RIDGELINE PICK UP 06-14 INSTALLATION INSTRUCTIONS BLACK MODULAR GRILLE GUARD FOR HONDA RIDGELINE PICK UP 06-14 PART # 17A152500A1MA Page 1 of 6 6/14/10 Rev1(DP...
-
Page 2: Parts List
BLACK MODULAR GRILLE GUARD FOR HONDA RIDGELINE PICK UP 06-14 PARTS LIST: Qty Description Description Grille Guard 10mm Lock Washer 8-1.25mm Nut Plates (06-08 models Driver/Left Frame Mounting Bracket only) 8-1.25mm Clip Nuts (09-10 models Passenger/Right Frame Mounting Bracket only) Tall Top Support Brackets (06-08 models only) 8-1.25mm x 25mm Button Head Bolts Short Top Support Brackets (09-10 models only) - Page 3 BLACK MODULAR GRILLE GUARD FOR HONDA RIDGELINE PICK UP 06-14 4. Repeat Step 3 for the passenger side Mounting Bracket installation, (Figure 2). IMPORTANT: On 09- 10 models, replace the (1) factory 10mm hex bolt in the passenger side of the cross-member with the provided longer (1) 10-1.25mm x 35mm Fine Thread Hex Bolt, (1) 10mm Lock Washer and (1) 10mm Flat Washer, (Figure 2).
- Page 4 BLACK MODULAR GRILLE GUARD FOR HONDA RIDGELINE PICK UP 06-14 (Fig 1) Driver side installation pictured If necessary, replace the If necessary, replace these factory 10mm Hex Bolt (too two with the provided: short) with the included: (2) 12-1.25mm x 35mm Fine (1) 10-1.25 x 35mm Fine Thread Hex Bolts Thread Hex Bolt...
- Page 5 BLACK MODULAR GRILLE GUARD FOR HONDA RIDGELINE PICK UP 06-14 DRIVER SIDE INSTALLATION PICTURED 06-08 Models use (1) 8mm Nut Plate (not pictured) 09-10 Models use (1) 8mm Clip Nut (pictured) (1) 8mm x 25mm Button Head Bolt (1) 8mm Lock Washer (1) 8mm Flat Washer Front (3) 12mm x 30mm Hex Bolts...
- Page 6 BLACK MODULAR GRILLE GUARD FOR HONDA RIDGELINE PICK UP 06-14 List for wing setting ① Nuts M8 ② Flat Washer D8 (8x24x2mm) ③ Button Head Bolts M8_25 ④ Lock Washers D8 ⑤ Allen Wrench S=5 Instruction for two wings Page 6 of 6 6/14/10 Rev1(DP...
