- Page 1 Assembly Instruction Bonnlo Nightstand Thank you for your purchase. Please contact us if you have difficulty with assembly or need replacement parts. Bonnlo Customer Service team is here to assist you. Here is how we can connect: Email: support@bonnlo.com...
- Page 2 Components DESCRIPTION TOP BOARD LEFT SIDE PANEL RIGHT SIDE PANEL 2PCS CROSS BAR BOTTOM CROSS BAR BACK CROSS BAR BACK PANEL 3PCS DRAWER FRONT BOARD 3PCS DRAWER LEFT SIDE PANEL 3PCS DRAWER RIGHT SIDE PANEL 3PCS DRAWER BACK BOARD 3PCS DRAWER BOTTOM BOARD...
- Page 3 PARTS DESCRIPTION 14PCS CAM BOLT 14PCS CAM LOCK 22PCS WOOD DOWEL 12PCS SCREW 3PCS SCREW 3PCS KNOB 10PCS BACK BOARD SCREW 24PCS SCREW 3PCS LEFT SLIDE RAIL SUPPORT 3PCS LEFT SLIDE RAIL 3PCS RIGHT SLIDE RAIL SUPPORT 3PCS RIGHT SLIDE RAIL 4PCS TOOLS NEEDED FOR ASSEMBLY: FLAT &...
- Page 4 STEP 1 STEP 1 1. Insert cam bolt (A) on drawer front board (8). 2. Attach drawer left side panel (9) and drawer right side panel (10) with drawer back board by using screw (D). 3. Put drawer bottom board (12) along the slot. STEP 2 STEP 2 1.
- Page 5 STEP 3 STEP 3 1. Attention：Please don’t mix right slide rail support (I) with left slide rail support (K). 2. Attach right slide rail support (I) to left side panel (2) with screw (H), and insert cam bolt (A) on left side panel (2).
- Page 6 STEP 5 STEP 5 1. Insert cam bolt (A) into top board (1). 2. Insert wood dowel (C) into side panel (2&3) 3. Connect side panel (2&3) with top board (1) by using cam lock (B). STEP 6 STEP 6 1.
- Page 7 24 hours. If you are enjoying your product and have just 2 minutes to spare, will you consider to leave us a review? Thank you so much. Sincerely, Bonnlo Bonnlo Customer Service Email: support@bonnlo.com...
