- Page 1 INSTRUCTION MANUAL Rev00(A) PIRTS06WN TV Console support@pipishell.net (US/CA) 1-800-556-9829 www.pipishellav.com (UK) 44-808-196-3885 WWW.
- Page 2 1-800-556-9829 (US/CA) / 44-808-196-3885 (UK) or customer service at support@pipishell.net. CAUTION: Avoid potential injuries and property damage! • DO NOT use this product for any purpose that is NOT explicitly specified in this manual.
- Page 3 Contents Left Middle Frame Right Middle Frame Mesh Panel Bottom Panel [1] x 1 [2] x 1 [3] x 1 [4] x 1 [5] x 4 Bottom Frame Top Support Bar Left End Frame [6] x 1 [7] x 2 [8] x 1 Right End Frame Top Panel...
- Page 4 M6 x 30mm M3.5 x 12mm M6 x 12mm Bolt Screw Bolt Adjustable Foot [A] x 12 [B] x 4 [C] x 8 [D] x 4 M6 x 23mm M4 x 12mm 5/32'' (4mm) Bolt Screw Handle Allen Key [E] x 14 [F] x 8 [G] x 4 [H] x 1...
- Page 5 STEP 2 Phillips Screwdriver (Not lncluded) TOP SIDE NOTE: The feet should face out. [4]*1 [5]*4 [6]*1 B*4 C*8 D*4 H*1...
- Page 6 STEP 3 E*4 H*1 STEP 4 NOTE: The large holes on support bars [7] must face out. [7]*2 E*4 H*1...
- Page 7 STEP 5 Back [8]*1 [9]*1 NOTE: The support bars on frames [8] and A*8 H*1 [9] must face in with the lip toward the back. STEP 6 [10]*1 E*6 H*1 Remember to fully tighten all bolts or screws after Step 6 is finished.
- Page 8 STEP 7 Phillips Screwdriver (Not lncluded) NOTE: If the unit is not level, adjust the feet by turning to [11]*4 [12]*4 raise or lower each corner. F*8 G*4 860-00845-00 Rev00...
