- Page 1 INSTRUCTION MANUAL Rev00(A) PISRB4 Shoe Rack support@pipishell.net (US / CA) 1-800-556-9829 (UK) 44-808-196-3885 www.pipishellav.com WWW.
- Page 2 Contents ① x 1 ② x 2 ③ x 2 ④ x 2 ⑤ x 2 ⑥ x 2 ⑦ x 4 M6 x 35mm M6 x 30mm A x 24 B x 4 C x 4 D x 1 E x 2...
- Page 3 STEP 1 ⑥ ⑥ ④ ⑤ ⑤ STEP 2 ④ ⑤ ③...
- Page 4 STEP 3 NOTE: Please keep the frames ④ on the same side. ④ ② ⑤ ④ ⑤ ② ② STEP 4...
- Page 5 STEP 5 NOTE: Please keep the raised edge downward when installing the mesh panels. Option A ⑦ ⑦ ⑦ ⑦...
- Page 6 Option B...
- Page 7 STEP 6 ① ①...
- Page 8 STEP 7 Electric Drill (NOT lncluded) E x 2 1 3/8″ ( 40 mm) 1 3/16″ (35mm) ø5/64″ (2mm) ø5/16″ (8mm) For Concrete or, Solid Wall or Brick Wall For Wood Stud Installation Installation 860-00318-00 Rev00...
