Rampage Products 5089925 Installation Instructions

99-19 Universal
1) From engine compartment at the backside of the grille, unplug the headlight.
2) Remove 3 screws on Headlight bezel on TJ models (4 screws on YJ models.)
3) Pop bezel out from grille assembly.
4) Remove 4 torx screws from headlight ring taking care to not drop the headlight, it
5) Lay new headlight on a padded surface, face down. Unclasp the spring clip where
6) Install bulb into socket, taking care NOT to touch the bulb glass.
7) Reinstall the spring clip, making sure the bulb is held in securely.
8) Place rubber boot over the back of the socket. Firmly press the center of the boot
9) Install new headlight assembly in to headlight bucket, make sure the word "TOP"
10) Reinstall the headlight ring.
11) Reinstall the bezel.
12) Reconnect the headlight plug from behind the grille in the engine compartment.
13) Repeat steps on other side.
14) Test headlights
Installation Instructions
HEADLIGHT CONVERSION KIT
will be loose after the screws are removed.
the bulb goes in a n remove the plastic insert from the back of the headlight
down around the back of the bulb so the prongs of the bulb are beyond the rubber.
that is molded into the glass is up.
Rampage Products Buford, GA
Phone: 800-328-2409
Rampageproducts.com
IS-HLKIT-508
Part Number
5089925 &
5089927
