Delta 101 HL3004 Assembly Instructions

Expanding
Beverage
Ring
Assembly instructions
Determine which shim ts your needs.
1
Insert into clamp.
Attach beverage holder to handlebar.
2
Tighten with thumb screw.
WARNING
Drinking a beverage while riding can cause accidents resulting in serious injury.
Ensure the beverage ts snugly in the holder before riding. Max Beverage Size: 24 oz.
Important: Nuts and bolts can loosen over time, resulting in severe danger should the item fall o
while in motion. Check frequently to ensure all bolts are properly tightened. Not for o -road use.
Avoid bumps which could dislodge beverage.
HL3004
