Satechi SA-ST-TCDMMAM Instructional Manual

DUAL MULTIMEDIA ADAPTER
1
Plug the Dual Multimedia Adapter into the two USB-C ports
on your laptop.
LED indicator light will illuminate when connected
3
Use HDMI cables to connect up to two HDMI-enabled monitors.
One port supports 4K 60Hz and the second 4K 30Hz
Requires a direct HDMI to HDMI connection
4K
5
Connect USB peripherals to USB 3.0 ports.
Does not charge iPad or support Apple SuperDrive
7
We recommend safely ejecting devices and disconnecting the adapter from your laptop when not in use.
I N S T R U C T I O N A L G U I D E
2
4
6
Connect your laptop's power adapter to the USB-C PD
charging port.
Max output: 60W
4. Plug in an Ethernet cable to the Ethernet port for wired
network connection.
Supports 10/100/1000Mbps
Insert Micro/SD cards into card reader slots.
Data speeds up to 104 Mbps
