Satechi ST-P3D13K Quick Manual

13-IN-1 USB-C TRIPLE DISPLAY
1
Connect the adapter to a compatible host device.
LED indicator would turn on once connected.
3
Connect HDMI cables from the adapter to a 4K HDMI-
equipped display.
Up to 4K at 60Hz.
Only supports direct HDMI connections.
MST-supported for multi-display function for some
Windows PCs.
macOS, iOS, and iPadOS devices support only one extended display at a time.
Any other monitors connected to the adapter will output mirrored displays.
QUICK GUIDE
MULTIPORT ADAPTER
4K
60Hz
2
UP TO
10Gbps
100W
Connect USB-C charging cable to either USB-C PD port.
Supports up to 100W, max 85W downstream (15W used
for operation), USB 3.1 data transfer speeds (10Gbps).
Does not support video output. Does not support CD/
DVD Drives or Apple SuperDrive.
4
PD Data
Connect DisplayPort cable from the adapter to a 4K
DisplayPort-supported display.
Up to 8K at 60Hz via Windows PCs.
Up to 4K at 160Hz via Apple devices.
Only supports direct DisplayPort connections.
MST-supported for multi-display function for some
Windows PCs.
PD Data
UP TO
PD Data
8K
4K
60Hz 160Hz
