Satechi ST-P8KED Quick Manual

USB-C MULTIPORT ADAPTER 8K
1
Connect the adapter to a compatible USB-C port on your
host device.
3
UP TO
100W
Use the USB-C PD port to charge your device up to 100W.
~15W is used for adapter operation.
Video and data transfer not supported.
5
Connect an Ethernet cable to the adapter's Gigabit Ethernet
port.
QUICK GUIDE
WITH ETHERNET V3
UP TO
1 Gbps
2
UP TO
8K/30Hz
Use the HDMI port to output video to an external monitor or
display – up to 8K at 30Hz or 4K at 60Hz/120Hz/144Hz.
Computer, cable, and monitor must support 8K.
8K video output not supported on Mac devices.
4
UP TO
10 Gbps
B
USB-C data ports allow for transfer data at up to 10 Gbps
(A, B, C) and 5 Gbps (D) speeds.
Does not support video output, charging or CD readers
including the Apple SuperDrive.
6
SD card reader supports up to UHS-II read/write speeds.
A
UP TO
5 Gbps
C D
UP TO
312 MB/s
