Wahl 8081 Manual

MAINS CLIPPER
BLADE REPLACEMENT AND ALIGNMENT
Top blade
BLADE REPLACEMENT
Remove both screws from the
blade.
BLADE ALIGNMENT
Loosen the screws enough
so the blades are still held
in place, do not remove the
screws.
If the blades fail to cut after alignment, cleaning, oiling and adjustment then there may be a problem with the internal tension in
the clipper or the blade could be blunt. It should be returned for service or service exchange (with blade).
Contact us for your Wahl product servicing needs or routine Wahl blade sharpening.
Bottom blade
Clean dirt and hair from the
clipper using a small brush.
1
2
If the clipper has a taper lever,
put it in the upmost position
(1).
Before you start it is important to know which is the
top blade and which is the bottom blade.
Oil the underside of the bottom
blade.
1
Position the tips of the top blade
teeth between 0.8-1.6mm back
from the bottom blade (1).
This step is important so the
blades do not cut too close or
allow the moving blade to touch
the skin.
Rest the top blade on the clipper
and put the bottom blade on top
with the flat side facing towards
the top blade.
Tighten the screws to hold the
blades in place.
2
3
Left Right
The extreme left hand tooth of
the top blade (2) must be cov-
ering, or be to the left of the first
small tooth of the bottom blade.
The extreme right hand tooth of
the top blade must be touching
the big tooth on the bottom
blade (3).
