Twin Cam Inner Cam Bearing Remover Kit
1
2
Item
No.
Qty.
1
4
2
1
3
1
4
1
5
2
6
2
WARNING: Wear eye
protection that meets ANSI
Z87.1 and OSHA standards.
© Bosch Automotive Service Solutions Inc.
655 Eisenhower Drive
Owatonna, MN 55060 USA
Phone: (507) 455-7000
Tech. Serv.: (800) 533-6127
Fax: (800) 955-8329
Order Entry: (800) 533-6127
Fax: (800) 283-8665
International Sales: (507) 455-7223
Fax: (507) 455-7063
3
Description
Thumb Screw
Plate Installer, Cam Bearing
Dowel Pin
Forcing Screw
Inner Cam Bearing Puller
Remover Body
Parts List &
Operating Instructions for:
5
4
6
Item
No.
Qty.
Description
7
1
Brass Washer, ¾-in.
8
1
Nut, Hex
9
2
Installer Tool, Cam Bearing
10
1
O- Ring
11
1
Driver Tool, Cam Bearing
Form No. 579899
6
9
9
8
7
Sheet No.
1 of 2
Issue Date: Rev. A, April 19, 2017
4847
4847A
11
10
