Naomi Home Odelia 20216B Assembly Instructions

N A O
H O M E
A - Seat Base
B - Back Rest
C - Back (seated) Right
D - Back (seated) Left
M I
Odelia Swivel Gliding Recliner
1. Unpack A - Seat Base and turn over upside down.
Remove any packing straps or materials from underside
of Seat Base securing the footrest from opening.
2. Select A - Seat Base and B - Back Rest.
With Backrest Buttons facing inward, carefully
align backrest mounts to seatbase mounts.
Insert bottom backrest mounts into Seat Base
Mounts until they latch and backrest is secured
to seatbase. Exercising Caution, Carefully lift
upward on the backrest to con rm backrest is secured.
C
5. Congratulations! Setup of your new
Naomi Home Odelia Swivel Gliding Recliner
is complete!
Note: pull the right (seated) handle
to release the footrest from the closed
position.
Assembly Instructions
D
B
B
B
A
A
3. Select C - Back (seated) Right. Insert mount
on C into mount on B - Back Rest (if sitting - right
side, if standing facing left side).
4. Repeat for D - Back (seated) Left.
