WESTBRASS 593244 Manual

Up To 14"
WESTBRASS 2429 East Olympic Blvd., Los Angeles, CA 90021
213-627-8441 • FAX 213-627-2844 • www.westbrass.com • info@westbrass.com
Fine Decorative Plumbing Since 1935
Tub
Wall
D329 Overflow
Cover - 3-1/8" dia.
792WS
2-1/4" ID
3-3/8" OD
D3322
Tub
Floor
1/8"
Up To 7-1/2"
593244
White Poly Slip Joint
Waste & Overflow
With mushroom tip toe and 2-hole overflow closure
792FH
1/4" - 20 x 1-1/2"
Flat Head Screw
D3322-1
Mechanism
D3322-2
1-7/8" - 11-1/2
1-1/2" NPSM
NPSM Thread
109606W Optional Extension
1-1/2"
1-1/2" Slip Joint
6-1/8"
1-1/2"
2"
