Topgreener TGTTDL300 Installation Instructions

INSTALLATION INSTRUCTIONS
Model: TGTTDL300
Table Top Lamp Dimmer
FEATURES
• Easy Plug and Use
• No programming required
• 6ft cord
• Smooth dimming slider movement for maximum control over
light level adjustment
• For use with 120V incandescent/halogen, Dimmable CFL or
Dimmable LED lights
SPECIFICATIONS
Rating .........................................................................120V~60Hz
Incandescent/Halogen..........................................................360W
CFL/LED/Self Ballasted........................................................150W
WARRANTY
This device is warranted to be free of material and workmanship defects for 1 year from the date of purchase. Original receipt or proof of purchase from an authorized retailer must be presented upon warranty claim.
ALL claims must be verified and approved by Top Greener, Inc. Warranties from other Top Greener products may vary. This warranty is nontransferable and does not cover normal wear and tear or any malfunction,
failure, or defect resulting from misuse, abuse, neglect, alteration, modification, or improper installation. To the fullest extent permitted by the applicable state law, Top Greener shall not be liable to the purchaser or
end user customer of Top Greener products for direct, indirect, incidental, or consequential damages even if Top Greener has been advised of the possibility of such damages. Top Greener' total liability under this or
any other warranty, express or implied, is limited to repair, replacement or refund. Repair, replacement or refund are the sole and exclusive remedies for breach of warranty or any other legal theory.
NOTES
FIRE HAZARD: DO NOT exceed maximum Wattage
•
specified.
Use Dimmable bulbs only
•
DO NOT use with 3-way bulbs
•
STRANGULATION HAZARD: KEEP CORDS AWAY FROM
•
CHILDREN!!!
INSTALLATION
1. Turn Off the power on the lamp and unplug the lamp.
2. Slide the control lever on the TGTTDL300 dimmer to the
Off position.
3. Plug in the TGTTDL300 into a live outlet.
OPERATING THE DIMMER
Control Lever
1. Plug the lamp into the TGTTDL300.
2. Turn the lamp On.
3. Slide the control lever up to brighten the lamp and
slide down to dim.
a. To turn Off the lamp completely using the
TGTTDL300, slide the control lever all the
way down until you feel a slight click (that's
the Air Gap on the switch)
© 2018 Top Greener, Inc. ● CA, U.S.A. ● WWW.TOPGREENER.COM ● 0205180118-01
