SOMIC G710 User Manual

Product Features
• Stereo Music Play / Pause Volume Adjustment /
Song Selection / Microphone Switch and Other Functions
• Phone Answer / Hang Up / Reject / Redial
• Operation Voice Prompts
• Headset Low Volume Alert
• Low Latency Game Features(USB Dongle Connection)
Specifications
Bluetooth Version
Transmit Power
Wireless Connectivity Range
Working Frequency Range
Headset Battery Capacity
Charger Specification
Battery Charging Time
Battery Working Time
Weight(Headphones)
Bluetooth Protocol
Audio Decoding
Headset Controls
①Turn Up Volume / Switch to Next Track
Short press the button once to increase sound volume; Long press the button to switch to the next
track ( "Max Volume" tone beeps when sound reaches a maximum)
②Multi-functional Buttons: MFB
(1)In the off state, long press the button for 2 seconds, the headset will automatically turn on.
(2)In the power-on state, press and hold the button for 3 seconds, the headset will automatically turn off.
(3)In the off state, press and hold the button for 6 seconds to enter the pairing state.
(4)Short press the button once to pause/play the music.
(5)When a call comes in, short press the button once to answer the call; long-press the button for 1
second to reject the call.
During a call, short press the power button once to hang up the call.
③Turn Down Volume/Switch to Previous Track
Short press the button once to decrease sound volume; Long press the button to switch to the
previous track ("Min Volume" tone beeps when volume reaches a minimum.)
④Microphone Switch/Audio Mode Switch
(1) Press once for microphone off with voice prompt "MIC OFF"; press again for microphone on with
voice prompt "MIC ON".
(2) Long press the button for 3 seconds to switch Gaming/Music mode.
★⑤Microphone 3.5mm Interface：
Need to insert the microphone to use the microphone function normally.
★⑥Line IN 3.5mm Audio Input Interface:
When inserted the 3.5mm plug cable, the headset is automatically turned off and the headset
⑦Type-c Charging Port:
The specification of the connected charger is DC5V/1000mA, the headset will automatically shut
down when inserted for charging.
⑧Working Indicator:
(1)Blue light flashes slowly when it's powered on.
(2)Red and blue lights flash repeatedly on pairing mode.
(3)The blue light flashes quickly when the call comes in and turns solid after answering the call.
(4)Red light flashes twice for 3 seconds when it's on low battery.
⑨Charging Status Indicator:
Solid red light when it's' charging; when it's fully charged, the red light will be off and turn solid green.
⑩Left and Right Headphones Lights:
The headset light will be solid on/off after it's powered on/off.
Quick Start Guide
1. Power on and Pairing
(1)Manual pairing: In the off state, long press the multi-function button for 6 seconds, the headset
will directly enter the pairing state after power on.
(2)In the off state, long press the ② button for 2 seconds, the Bluetooth headset will into the
power-on state (voice prompt "Power on"). If the pairing was made before, the headphones will
switch automatically to pairing. Otherwise, the headset will start the pairing mode (voice prompt
"Pairing"). In the pairing state, search for available Bluetooth-enabled devices like mobile phone
and exit the pairing state after a successful connection.
(3)After the headset enters the pairing mode, the status lights will blink red and blue repeatedly.
Turn on the connecting Bluetooth device and go to the Bluetooth menu on your smartphone
and select the "G710" from the list of available devices. When the device and the Bluetooth
headset are connected, you will hear the tone "Connected". After successfully connecting, the
blue light of the headset will flash slowly.
(4)Bluetooth transmitter pairing: Insert the Bluetooth transmitter into the USB port of the computer.
when the headset was recognized by the devices, the blue indicator flashes slowly. With a pin
through the round hole on the transmitter and press inside for 2 seconds to pair, you will see the
blue light fast flashing, which indicated that it's pairing. When the Bluetooth transmitter and
headset are successfully paired, the voice prompt "Connected". The blue lights on the Bluetooth
transmitter will be solid.
★Notes:
When the headset is shipped, the headset and USB transmitter have been paired. Please plug the
USB transmitter into the USB port of the computer and the headset will automatically connect when
it is turned on.
(If the connection fails, please follow the above steps to re-pair the headset and USB transmitter.)
Troubleshooting
Troubleshooting
Unable to boot
Unable to pairing
The headset has noise
Connection interruption
Short reception distance
Warranty
SOMIC products are covered by a 12-month limited warranty from the date of its original purchase.
If any problem occurs, please contact our support team, we will always be here to help you solve
the problem. If you want to know more information, please visit Somic' s official website
www.itsomic.com.
www.itsomic.com
Service E-mail
NORTH AMERICA
support.us@itsomic.com(US)
support.ca@itsomic.com(CA)
ASIA PACIFIC
support.jp@itsomic.com(JP)
EUROPE
support.eu@itsomic.com(EU)
AUSTRALIA
support.au@itsomic.com(AU)
MANUFACTURER
Manufacturer:
Dongguan Branch of Guangdong SOMIC High-Tech Co., Ltd
Address:
No.9, Lianxin Road, Shangjiao Community, Chang'an Town,Dongguan 523000,Guangdong, China
Possible Reason
The battery power is insufficient
(Bluetooth Mode) Smartphone hasn't yet
opened the Bluetooth function or hasn't yet
opened the discoverable status.
(Bluetooth Mode/ 2.4GHz Wireless Mode)
When paired, the headphones are too far
from the USB transmitter/smartphone.
The battery power is insufficient
The battery power is insufficient
1. The headset is stay too far from the device
to the transmitter between receiving ranges.
2. The headset is affected by an obstacle
between the distance from device to
the transmitter.
1. Transmitter device compatibility issues.
2. The headset is affected by an obstacle
between the distance from device to the
transmitter.
Package Contents
• 1 x Gaming Headset
• 1 x Type-C Charging Cable
• 1 x USB Transmitter
• 1 x Microphone Pole
• 1 x 3.5 mm Splitter Cable
• 1 x User Manual
V5.2
CLASS2
10 Meters
2402-2480MHZ
1000mAh
DC 5.0V 1000mA
3 Hours
28 Hours
≈285g
HFP1.7/HSP1.2/A2DP1.3/AVRCP1.6
AAC/SBC
Exclusion Method
Charge the battery in time
Start Bluetooth and set to dicoverable
Please don't be far away from the device within
1 meter when connected and stay away from the
interference sources like GPS/WiFi.
Charge the battery in time
Charge the battery in time
Read just to the right position while using
1. Try using a different transmitter.
2. Read just to the right position while using.
