SOMIC GS510 User Manual

Product Features
• 2 Modes Connection-Bluetooth 5.0
3.5mm Audio Cable Connection
• 3 Professional Audio Modes -Gaming/Live/Music
• Retractable & 120° Rotting Microphone
• Magnetic Speaker Tags Design
• 8 RGB Lighting Effects + One Multi-color Cycling Mode
Specifications
Model
Bluetooth version
Driver Diameter
Directivity(Mic)
Sensitivity(Mic)
Impedance(Mic)
Impedance (Headphones)
Sensitivity (Headphones)
Frequency Response (Headphones)
Headset Battery Capacity
Battery Working Time
Battery Charging Time
Communication Distance
Headset Controls
Mode switch
Power on/off
Microphone on/off
Volume+/-
Power On/Off
In the off state, long press the power button for 2 seconds, the headset will automatically turn on.
In the power-on state, press and hold the power button for 3 seconds, the headset will
automatically turn off.
3 Modes Switch
Short press the " mode" button once to switch the mode:
Gaming Mode/Music Mode/Live Mode
Music Pause/Play
Short press the power button once to pause/play the music.
Call Mode
When a call comes in, short press the power button once to answer the call.
When a call comes in, short press the power button twice to reject the call.
During a call, short press the power button once to hang up the call.
Light On/Off
Three-click the lighting touch key to turn on/off the headset light.
Light Color Switch
Press the lighting touch key for 2 seconds to switch the light color.
Charge
It is recommended to fully charge the headset before first use.
1. When the headset is charging, the battery indicator shows a solid orange light.
When the headset is fully charged, the battery indicator shows a solid green.
2. When the power of the headset is less than 10%, the headset will emit a""Please Charge""prompt,
please charge it in time.
Quick Start Guide
Connect Headphones to Device via Bluetooth (Compatible with Smartphone)
1. Long press the headphone power button for 2 seconds, release the button after the light is
always on, and the headset powered on successfully.
2. When the power on is successful, the headset automatically enters the pairing state, and the
power on indicator light will rapidly blink blue.
3. Open the Bluetooth settings when you connect the headset for the first time, search and select
the device""SOMIC STINCOO GS510"", and the power-on indicator will be solid blue after the
connection is successful
(The headset will automatically connect to your phone after being paired the first time)
4. If the connection fails, it will automatically enter the re-pairing mode. If there is no device
available within 3 minutes, the headset will automatically shut down.
★Notes:
If connection fails, please try again after fully charging.
Connect Headphones to Device via 3.5mm Audio Cable
(Compatible with PS5/PS4/Xbox One/Xbox Series X/S Controller/Nintendo Switch)
1. Connect the 3.5mm headphone cable to the headphone port on the headset.
2. Plug the 3.5mm headphone cable into your device.
★Notes:
In wired mode, the headset light don't work, all buttons are disable except for
adjusting the volume+/-."
★Other microphone problems or questions of the headset, please contact SOMIC
support team.
Troubleshooting
Troubleshooting
Unable to boot
Unable to pairing
The headset has noise
Caution
1. Bluetooth mode supports most products of Bluetooth devices.
2. If it is not available on the operating system or equipment that is not listed, you can contact
the support team for help.
3. When using the headset, if there is no sound from the microphone or headset itself, it may
be caused by compatibility problems or improper use, and you can contact our after-sales
service for help.
4. If any part is damaged, such as a broken cable, please stop using it and contact the after-sales
service for help to avoid unnecessary losses.
5. If you want to know more information, please visit Somic's official website www.itsomic.com
Warranty
SOMIC products are covered by a 12 months limited warranty from the date of its original purchase.
If any problem occur, please contact our support team, we will always be here to help you solve the
problem. If you want to know more information, please visit Somic' s official website www.itsomic.com.
www.itsomic.com
Service E-mail
NORTH AMERICA
support.us@itsomic.com(US)
support.ca@itsomic.com(CA)
ASIA PACIFIC
support.jp@itsomic.com(JP)
EUROPE
support.eu@itsomic.com(EU)
AUSTRALIA
support.au@itsomic.com(AU)
MANUFACTURER
Manufacturer:
Dongguan Branch of Guangdong SOMIC High-Tech Co., Ltd
Address:
No.9, Lianxin Road, Shangjiao Community, Chang'an Town,Dongguan 523000,Guangdong, China
MODEL:GS510
SOMiC Bluetooth Headset
User Manual
Reset button
Possible Reason
The battery power is insufficient
(Bluetooth Mode) Smartphone hasn't yet
opened the Bluetooth function or hasn't yet
opened the discoverable status
(Bluetooth Mode) When paired, the
headphones are too far from the devices
The battery power is insufficient
The battery power is insufficient
Package Contents
• 1 x Cat Ear Headset
• 1 Pair x Speaker Tags
• 1 x 3.5 mm Audio Cable
• 1 x Type-C Charging Cable
• 1 x User Manual
GS510
5.0
Ø50mm
Omnidirectional
36dB±3dB
≤2.2KΩ
32Ω
100±3db
20Hz ~ 20KHz
1500mAh
8-10 Hours
2 Hours
10 Meters/33 Feet
AUX interface
Exclusion Method
Charge the battery in time
Start Bluetooth and set to dicoverable
Please don't be far away from the device within
10 meters when connected and stay away from
the interference sources like GPS/WiFi.
Charge the battery in time
Charge the battery in time
L
Light touch key
