Echogear EGAV-CMIWPTDW Installation Instructions

#YourGearUpgraded
IN-WALL CABLE PASS THROUGH - DUAL GANG
EGAV-CMIWPTDW
Model
Installation Instructions
Doc. #1507329 11/19 Rev A
IMPORTANT SAFETY INSTRUCTIONS
PLEASE READ ENTIRE MANUAL PRIOR TO USE
SAVE THESE INSTRUCTIONS
but read it, so you don't jack things up!
Yea, the boring stuff ...
CAUTION:
Avoid potential personal injuries and property damage!
● FOR LOW VOLTAGE CABLES ONLY.
● RISK OF FIRE - DO NOT install power supply cord within the wall cavity.
● Do not use this product for any purpose not explicitly specified by manufacturer.
● Manufacturer is not responsible for damage or injury caused by incorrect
assembly or use.
● If you do not understand these instructions or have doubts about the safety of
the installation, assembly or use of this product, contact The Echogear Pros at
www.echogear.com.

3—7/8"
Remember the last time
you "winged it"?
Cut out this template
for STEP 2
Cutting
Template
©2019 Legrand AV Inc. All Rights Reserved. ECHOGEAR is a Legrand AV Inc. brand and a registered trademark owned by Legrand. Made in China.
Grab Your Tools
Pencil Level
Confuzzled?
Contact the ECHOGEAR Pros:
1 THE SWEET SPOT 2
Your Desired Location
