Axxess ASWC-1 Installation Instructions

The ASWC-1 has the capability to assign (2) functions to a single button except for Volume Up and Volume Down, after the ASWC-1 has been programmed and is fully functional. This feature can be performed
by either following the steps below, through a Windows based computer using the Axxess Updater, or through the Axxess Updater app available from the Android/Apple mobile devices app store.
Note: Apple mobile devices will require the use of the AX-HUB for this feature.
Attention! If more than 20 seconds elapses between steps, the procedure will abort, and the ASWC-1's light will go out. The ASWC-1 may not function properly and may need to be reset and reprogrammed.
1. Turn the key to ignition and wait until the ASWC-1's light flashes
2. Press and hold the Volume Down button on the steering wheel until the ASWC-1's light turns on solid Red, then release. The light will then go out indicating that the ASWC-1 is in Changing Radio
Type mode.
3. Refer to the Radio Legend to reference the radio number for the radio being installed.
4. Press and hold the Volume Up button on the steering wheel until the ASWC-1's light turns on solid Red, then release. Repeat this step for the desired radio number selected.
5 Once the desired radio number has been selected, press and hold the Volume Down button on the steering wheel until the ASWC-1's light turns on solid Red. The light will remain on solid
roughly 3 seconds while it stores the new radio information. After the light goes out, test the steering control wheel controls for functionality.
Radio Legend
Radio # Radio
1 Eclipse (type 1)
2 Kenwood
3 Clarion (type 1)
4 Sony / Dual
5 JVC
6 Pioneer / Jensen
7 Alpine
8 Visteon
9 Valor
Changing Radio Type
Green 1 time then goes out.
Radio # Radio
10 Clarion (type 2)
11 Metra OE
12 Eclipse (type 2)
13 LG
14 Parrot
15 XITE
16 Philips
17 TBA
18 JBL
Integrate •
© COPYRIGHT 2018 METRA ELECTRONICS CORPORATION
INSTALLATION INSTRUCTIONS
AxxessInterfaces.com
REV. 11/16/18
ASWC-1
Red for
