- Page 1 SKU:CTBS-5T-009 5-Tier Bookshelf with Back User Manual...
-
Page 2: Disassembly Diagram
Disassembly Diagram Before assembly, please read the USER MANUAL thoroughly for quick assembly, and check according to Accessories. lf you have any concerns or questions during installation or about product itself, please feel free to contact us via Amazon Orders or Customer Support Email: Furologeeservice@sincerehl.com... - Page 3 Accessories A x 4+1 B x 34+2 C x 16+1 D x 8+1 3.5x35 Ø5x40 M6x12 M6x22 E x 4+1 F x 4 G x 2 H x 2 TOOL 10mm Ø30xM6x25 Ø11.5...
- Page 4 Step 1: Connect the tube 1 with connectors 2 Step 2: Connect the tube 2 with connectors 3 and 4...
- Page 5 Step 3: Connect the tube 3 and 4 with connectors 5 and 6 Step 4: Assemble the adjustable feet...
- Page 6 Step 5: Assemble the shelf board 7 and back board 8 Step 6: Assemble the frame and shelf hole facing outward for subsequent steps...
- Page 7 Step 7: Assemble part 9 Step 8: Assemble part 10 to make the bookshelf more stable 10 10 10mm...
- Page 8 Step 9: Cover the screw head...
- Page 9 Step 10: If necessary, install the anti-tip kits × √...
