- Page 1 5-Tier S Shaped Bookshelf User Manual...
-
Page 2: Disassembly Diagram
Disassembly Diagram Before assembly, please read the USER MANUAL thoroughly for quick assembly, and check according to Accessories. lf you have any concerns or questions during installation or about product itself, please feel free to contact us via Orders or Customer Support Email:... - Page 3 Accessories A x 14+1 B x 2+1 C x 16+1 ∅ M6x20 M6x25 5x40 E x 4 F x 1 D x 8+1 TOOL...
- Page 4 Step 1: Assemble the side board 4 and frame 5 with the bottom board 2 ; Stick the sponge E onto the bottom board large hole faces outward Step 2: Assemble the shelf board 3 with side board 4 and frame 5 large hole faces outward...
- Page 5 Step 3: Assemble the side board 4 and frame 5 with the shelf board 3 Step 4: Assemble the shelf board 3 with side board 4 and frame 5 large hole faces outward...
- Page 6 Step 5: Assemble the side board 4 and frame 5 with the shelf board 3 Step 6: Assemble the shelf board 3 with side board 4 and frame 5 large hole faces outward...
- Page 7 Step 7: Assemble the side board 4 and frame 5 with the shelf board 3 Step 8: Assemble the top board 1 with side board 4 and frame 5 large hole faces outward...
- Page 8 Step 9: Cover the hole cover D Step 10:If necessary, install the anti-tip kits...
-
Page 9: Problems You May Encounter
Customer Service 1-Year Warranty We guarantee your product is free from defects in ptoduct material and work manship for one(1)year starting from the date of purchase during normal use of household conditions. If your appliance fails within the limited warranty period, we will arrange a new replacement free of charge, and cover all the shipping costs.
