- Page 1 SKU:CTBS-6T-008 6-Tier Bookshelf User Manual...
-
Page 2: Disassembly Diagram
Disassembly Diagram Before assembly, please read the USER MANUAL thoroughly for quick assembly, and check according to Accessories. lf you have any concerns or questions during installation or about product itself, please feel free to contact us via Amazon Orders or Customer Support Email: Furologeeservice@sincerehl.com... - Page 3 Accessories A x 8+1 B x 34+2 C x 24+2 D x 2 Ø5x40 M6x12 M6x22 E x 4 F x 2 TOOL Ø30xM6x15...
- Page 4 Step 1: Connect the tube 1 with connectors 2 and 3 This hole will be This hole will be used in Step 8 used in Step 8...
- Page 5 Step 2: Connect the tube 2 and 3 with connectors 4 and 5 This hole will be This hole will be used in Step 8 used in Step 8...
- Page 6 Step 3: Connect the tube 4 and 5 with connectors 6 and 7 This hole will be This hole will be used in Step 8 used in Step 8...
- Page 7 Step 4: Connect the tube 4 and 5 with connectors 6 and 7...
- Page 8 Step 5: Assemble tube 8 to make the bookshelf more stable Step 6: Assemble the adjustable feet...
- Page 9 Step 7: Assemble the frame and shelf Note that these four holes are on the same side...
- Page 10 Step 8: Assemble part 9 to make the bookshelf more stable Use a wrench to install the nut...
- Page 11 Step 9: If necessary, install the anti-tip kits...
