Summary of Contents for DigiTech MULTI CHORUS
-
Page 2: Declaration Of Conformity
European Contact: Your local DigiTech Sales and apparatus has been exposed to rain or moisture, does Service Office or not operate normally, or has been dropped. - Page 3 6.The consumer forfeits the benefits of this warranty if the product's main assembly is opened and tam- pered with by anyone other than a certified DigiTech technician or, if the product is used with AC volt- ages outside of the range suggested by the manufacturer.
- Page 4 DigiTech has long been known as a leader in the guitar signal processing industry. The Multi Chorus is a culmination of this expertise, bringing you a breakthrough in chorus effect technology. Thanks to our proprietary AudioDNA™ processor, the Multi Chorus is the only pedal that provides up to16 independent voices of interactive chorusing.
- Page 5 2 3 4...
- Page 6 4. Depth Knob Controls the depth of the chorus effect. Turn this knob clockwise to increase the depth for a thick chorus sound, and counter-clockwise to decrease the depth for a shallow, light chorus sound. 5.Voice Knob Controls the number of chorus voices used. At the knob’s minimum position, only a single chorus voice is present.
-
Page 7: Indicator Led
Push these pins in to release the pedal from the pedal chassis exposing the battery compartment. (See battery replacement diagram.) 8. Pedal Press the pedal to turn the effect on and off. 9. Out 1(Mono) Jack Connect this output to a single guitar amplifier when only one amp is being used. - Page 8 Connections The Multi Chorus has a single input and a pair of outputs. Out 1 is used if the Multi Chorus is being connected to only one amplifier. Out 2 is used for stereo operation. Connect Out 1 to the first amplifier and Out 2 to the second amplifier.
-
Page 10: Battery Replacement
Battery Replacement 1. Using the tip of a 1/4” guitar cable, push one of the release pins in on either side of the pedal, and remove the pedal from the pedal chassis. 2. Remove the battery from the battery compartment and disconnect the battery cable. -
Page 12: Specifications
• Jacks - Input, Out 1 (Mono), Out 2 FAX (801) 566-7005 • Input Impedance - 1 MOhms DigiTech and X-Series are trademarks • Output Impedance - 100 Ohms of the Harman Music Group Inc. • Power Supply - 9V Alkaline Dry Battery •...
