- Page 2 European Contact: Your local DigiTech Sales and Service Office or apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
- Page 3 The Crossroads Artist Series Pedal was conceived in conjunction with Eric Clapton and his long-time guitar tech Lee Dickson. Crossroads models seven Clapton signature tones. From songs like “Badge” with its swirling rotary speaker modulation, to “Layla” (Unplugged) with its intimate acoustic tone, and of course, “Sunshine of Your Love”...
- Page 4 Eric Clapton Crossroads Artist Series Pedal includes the ® ™ following items: • DigiTech Eric Clapton Crossroads Artist Series Pedal • Artist Series Pedal Gig Bag • Eric Clapton Crossroads Artist Series Guitar Pick • PS200R Power Supply • This Owner’s Manual •...
- Page 6 Function Descriptions section on the following pages for a more detailed explanation of the CNTRL 1 knob’s functions. 3. AC Adapter Jack Connect only the included DigiTech ® PS200R (9V DC) power supply to this jack. 4. CNTRL 2 (Control 2) Controls different functions depending on which MODEL is selected.
- Page 7 Push these pins in to release the pedal from the pedal chassis 1.“Sunshine of Your Love” exposing the battery compartment. 2.“Crossroads” (See the Battery Replacement Diagram 3.“Badge” at the end of this Owner’s Manual) 4.“Layla”...
- Page 8 Knob Function Descriptions MODEL 1.“Sunshine of Your Love”,Cream – Disraeli Gears (1967) Perhaps one of Eric’s best known songs from the Cream years is “Sunshine of Your Love”. Eric achieved his now infamous “woman tone” on “Sunshine” in a rather unconventional manner.
- Page 9 MODEL 2.“Crossroads”, Cream – Wheels of Fire, Live at the Fillmore (1968) A pivotal moment in Eric’s career is the track “Crossroads” from Cream’s live 1968 recording Wheels of Fire, Live at the Fillmore. “Crossroads” was penned by Robert Johnson, Eric’s most important guitar influence.
- Page 10 panned hard left and hard right to hear the rotary speaker modulation effect at its best. CNTRL 1 adjusts the amount of overdrive gain for the guitar signal while CNTRL 2 adjusts the speed of the modulated sound. MODEL 4. “Layla”, Derek and the Dominoes – Layla and Other Assorted Love Songs (1970) Eric’s most recognized guitar riff and song is “Layla”.
- Page 11 MODEL 6.“Layla” (Acoustic),Eric Clapton – Unplugged [LIVE] (1992) A pivotal moment in Eric’s career was his live acoustic performance on the MTV television series “Unplugged”. ™ Here Eric and his band unleashed a variety of acoustic renditions of some of Eric’s most famous electric works, including his hit song “Layla”.
- Page 12 Connections Diagrams on the following pages.) 4. Connect the power supply to the pedal. (Please refer to the Connections Diagrams on the following pages.) 5. Set the Crossroads pedal’s LEVEL control to the minimum position. ™ 6.Turn up your amplifier/mixer level to your desired listening level.
- Page 13 (L/R), or any combination of the two outputs. The OUT 2 (MIXER) output has been specially designed to faithfully reproduce Eric’s studio guitar amplifier tones without having to use an amp. (Please refer to the Connections Diagrams on the following pages.) Crossroads Outputs Diagram...
- Page 14 Connections Diagram (Mono Amp or Stereo Amps)
- Page 15 Connections Diagram (Amp and Mixer) ® The dotted line represents a Stereo Mixer Application recommended for MODEL 3 MODEL 6 only.
- Page 16 Battery Replacement 1. Using the tip of a 1/4” guitar cable, push one of the release pins in on either side of the pedal, and remove the pedal from the pedal chassis. 2. Remove the battery from the battery compartment and disconnect the battery cable.
- Page 17 Battery Replacement Diagram...
- Page 18 • Input Impedance - 1 MOhms • Output Impedance - 100 Ohms • Power Supply - Included DigiTech PS200R or 9V Alkaline Dry Battery • Power Consumption - 4.8 Watts (w/PS200R power supply) • Battery Life - Approximately 4 hours (with continuous usage) •...
- Page 19 1.The warranty registration card must be mailed within ten days after purchase date to validate this warranty. 2. DigiTech warrants this product, when used solely within the U.S., to be free from defects in materials and workmanship under normal use and service.
- Page 20 DigiTech ® , Crossroads ™ , and Production Modeling ™ are trademarks of the Harman International. All other product names, trademarks and artists’ names are the property of their respective owners, which are in no way associated with DigiTech. www.crossroadsantigua.org...
