Geekworm X729 V1.3 User Manual

For raspberry pi ups, x729 ups (max 5.1v 6a) with wide 6-24v input

Table of Contents

Quick Links

Download this manual

Overview........................................................................................................................................................................ - 2 -

Update History............................................................................................................................................................... - 2 -

Features......................................................................................................................................................................... - 2 -

UPS Output ................................................................................................................................................................. - 2 -

Battery Charging........................................................................................................................................................ - 2 -

Power Input................................................................................................................................................................- 3 -

Power Management.................................................................................................................................................. - 3 -

RTC............................................................................................................................................................................. - 3 -

FAN.............................................................................................................................................................................- 3 -

Misc............................................................................................................................................................................ - 3 -

Specifications............................................................................................................................................................. - 3 -

Interface Schematic....................................................................................................................................................... - 4 -

Dimensions.....................................................................................................................................................................- 6 -

X729 V1.3 Packing List................................................................................................................................................... - 7 -

How to Power................................................................................................................................................................ - 8 -

Cooling Solution............................................................................................................................................................. - 8 -

Match Metal Case .......................................................................................................................................................... - 8 -

Software Guide.............................................................................................................................................................. - 9 -

Hardware Guide.............................................................................................................................................................- 9 -

Installation Video........................................................................................................................................................... - 9 -

Application ................................................................................................................................................................... - 10 -

FAQ...............................................................................................................................................................................- 14 -

Customer Service......................................................................................................................................................... - 14 -

Manual Revision History:............................................................................................................................................. - 14 -

https://geekworm.com

Geekworm X729 V1.3 User Manual

Content

Support: support@geekworm.com

- 1 -

Table of Contents

Need help?

Do you have a question about the X729 V1.3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Geekworm X729 V1.3

Page 1: Table Of Contents
Misc.................................... - 3 - Specifications................................- 3 - Interface Schematic............................... - 4 - Dimensions..................................- 6 - X729 V1.3 Packing List..............................- 7 - How to Power................................- 8 - Cooling Solution................................- 8 - Match Metal Case ................................- 8 - Software Guide................................
Page 2: Overview
Measure both output voltage and current draw over I2C with high precision Integrate Advanced Power MOSFET with Equivalent of 7mΩ RDS(ON) to reduce power loss Battery Charging Supports 3000mA fast battery charging Battery over current protection and over voltage protection https://geekworm.com Support: support@geekworm.com - 2 -...
Page 3: Power Input
Works with all current models of the Raspberry Pi using a 40 pin header XH2.54 connectors for extra battery x1, 5V output x2 PH2.04P for external power switch Specifications Power input: 6-24Vdc ±5%, ≥3A https://geekworm.com Support: support@geekworm.com - 3 -...
Page 4: Interface Schematic
UPS output : 5.1V ±5% Max 6A UPS charging current: 2.3~3.2A Terminal Battery Voltage : 4.24V Battery Recharge Threshold : 4.1V Interface Schematic https://geekworm.com Support: support@geekworm.com - 4 -...
Page 5 Support: support@geekworm.com - 5 -...
Page 6: Dimensions
Dimensions https://geekworm.com Support: support@geekworm.com - 6 -...
Page 7: X729 V1.3 Packing List
X729 V1.3 Packing List 1 x X729 V1.3 UPS Shield  2 x Jumper link Pitch 2.54mm  4 x M2.5 *7+6mm Spacers  4 x M2.5 *12mm Spacers  1 x M2.5 *20mm Spacers  5x M2.5 *4mm Screws ...
Page 8: How To Power
How to Power  Power via DC5521 Jack of X729 V1.3, Wide voltage input 6-24Vdc +/-5% , ≥ 4A (DC5525 Jack is compatible with DC5521) Cooling Solution  The X729 with an on-board PWM cooling fan to cooling down the Raspberry Pi, the fan speed is adjustable.
Page 9: Software Guide
Software Guide https://wiki.geekworm.com/X729-Software or scan QR Code Hardware Guide https://wiki.geekworm.com/X729-hardware or scan QR Code Installation Video No video. https://geekworm.com Support: support@geekworm.com - 9 -...
Page 10: Application
Application https://geekworm.com Support: support@geekworm.com - 10 -...
Page 11 Support: support@geekworm.com - 11 -...
Page 12 Support: support@geekworm.com - 12 -...
Page 13 Support: support@geekworm.com - 13 -...
Page 14: Faq
A: Because there are so many kind of batteries, and the quality is also various. So we suggest to use the NCR18650B from Panasonic. Also '''do not use''' 18650 battery with built-in protection circuit for X729. Customer Service Support: support@geekworm.com(Please attach order number and issue details.) Manual Revision History: Date...
