KwikBoost m8 Start Manual

Hardware:
#10 Screw
Qty. 2
Installation Tips:
• When installing base plate, place the upright pole on a countertop or
elevated surface, then attach base.
Suggested Tools:
Phillips Screwdriver
Assembly:
1
After removing contents from box, attach baseplate to upright
using 3/8"-16 machine screws.
2x
*Make sure square cutouts line up.*
2
Slide the m8 unit down into the aluminum mounting bracket.
3/8"-16 Machine Screw
Qty. 2
Assembly Continued:
3
Secure the m8 charger to the mounting bracket with #10 screws.
4
Plug the power jack into the bottom of the technology box.
5
Now that the charger is assembled, it can be plugged in.
The power cable will plug into any standard wall outlet or
power strip.
Questions? Concerns. Feedback?
kwikboost.com • 800.676.4278 • support@kwikboost.com
m8
Floor Stand Charger
2x
