Acuity Brands sensorswitch CMR 9 Manual

Catalog Number:
OVERVIEW
The CMR 9 Series Standard Range 360° occupancy sensor incorporates Passive Infrared (PIR)
detection technology into an attractive line powered occupancy sensor that provides amazing
sensitivity to small motions (e.g. hand movements) and excellent payback. The CMR 9 is an
economical solution for providing automatic lighting control where a wall switch replacement
sensor is not applicable. With an integrated line switching relay, the CMR 9 is perfect for
applications where locating a power pack is difficult, such as retrofitting rooms with concrete or
inaccessible ceilings. For rooms with obstructions, the CMR PDT 9 Series sensor is recommended.
With optional flash programming via the Sensor Switch VLP mobile device application, the user
can easily change time delay, on mode and photocontrol settings.
FEATURES
•
Push-Button Programmable, Adjustable Time Delays, and Multiple Operating Modes
•
100 Hour Lamp Burn-in Timer Mode
•
No Field Calibration or Sensitivity Adjustments Required
•
No Minimum Load Requirements
Warranty
Five-year limited warranty. Complete warranty terms located at:
www.acuitybrands.com/support/customer-support/terms-and-conditions
Note: Actual performance may differ as a result of end-user environment and application.
Specifications subject to change without notice
CMR 9
CMR 9
Series
CMR Ceiling Mount Sensor
Control Type
[blank] None
D Occupancy Controlled Dimming
1
DZ Dual Zone Photocell
2
P Photocell
ADC 1 Photocell w/ Dimming
Acuity Brands | One Lithonia Way Conyers, GA 30012 Phone: 800.535.2465 www.acuitybrands.com/sensorswitch
© 2014-2019 Acuity Brands Lighting, Inc. All rights reserved. Rev. 06/18/19
ORDERING INFORMATION
Detection Technology
[blank] PIR
PDT Dual Technology
(PIR / Microphonics)
Voltage
[blank] 120/277 VAC
347 347 VAC
Date: Project:
Coverage Type Relay
9 Small Motion 360˚ [blank]
2P
Visible Light Programming
[blank] None
VLP Visible Light
1,3
Programming
CMR 9
CMR PDT 9
Standard Range 360˚
Sensor
Example: CMR 9 ADC LT
Single Relay
Dual Relays
Temp/Humidity
[blank] Standard
LT Low Temp/High Humidity
Notes
1. Not available with 2P option.
2. Not available with single relay option.
3. PDT Required.
C US LISTED
CMR 9
1 of 3
