Acuity Brands nLight rSDGR Quick Start Manual

SPECIFICATIONS (rSDGR)
Electrical Specifications
Mechanical
Environmental Warrantied Operating Temperature
Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment.
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada's licence-exempt RSS(s). Operation is subject to the following two conditions:
1. This device may not cause interference.
2. This device must accept any interference, including interference that may cause undesired operation of the device."
L'émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d'Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée
aux deux conditions suivantes :
1. L'appareil ne doit pas produire de brouillage;
2. L'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
4. Consult the dealer or an experienced radio/TV technician for help.
SAVE THESE INSTRUCTIONS AND DELIVER TO OWNER AFTER INSTALLATION
• To reduce the risk of death, personal injury or property damage from fire, electric shock, falling parts, cuts/abrasions, and other hazards please read all warnings and instructions included with and on the fixture box and all fixture labels.
• Before installing, servicing, or performing routine maintenance upon this equipment, follow these general precautions.
• Installation and service should be performed by a qualified licensed electrician.
• Maintenance should be performed by qualified person(s) familiar with the products' construction & operation & any hazards involved. Regular maintenance programs recommended.
• To be installed to a circuit with overvoltage control to Overvoltage category Cat.III or less, minimum suppression rating 6.0 kV for a 600 V ac rms system voltage
DO NOT INSTALL DAMAGED PRODUCT! This product has been properly packed so that no parts should have been damaged during transit. Inspect to confirm. Any part damaged or broken during or after assembly should be replaced.
•
CAUTION: RISK OF PRODUCT DAMAGE
√ Electrostatic Discharge (ESD): ESD can damage product(s). Personal grounding equipment should be worn
during all installation or servicing of the unit.
√
√
√ Do not tamper with contacts.
√ Do not modify the product.
√ Do not change or alter internal wiring or installation circuitry.
√ Do not use product for anything other than its intended use.
Acuity Brands | One Lithonia Way Conyers, GA 30012 Phone: 800.535.2465
IS-RSDGR-001
Contains FCC ID: 2ADCB-RMODIT or 2ADCB-RMODIT3 Contains IC: 6715C-RMODIT or 6715C-RMODIT3 Contains IFETEL: RCPACRM18-1879 or RCPNLNL20-2057 Acuity Brands Lighting Inc. RMODIT
rSDGR Sensor
Fixture Integrated Motion and Photocontrol
360° COVERAGE LINE VOLTAGE
•
Input Ratings rSDGR 120-277VAC, 50/60 Hz 2.5W
rSDGR HVOLT 347-480VAC, 50/60 Hz 2.5W
Maximum Load 450 W @ 120-277
480 W @ 347-480
Dimming Load Sinks <6mA (0-10 VDC LED Drivers/Ballasts)
Minimum Load
None
Class Rating 0-10V Dimming can be wired Class 1 or 2
Mounting Fixture Mounted
Mounting Height Up to 40 ft (12.19m)
Connection Type Line and Low Voltage Leads
-40º to 149º F (-40º to 65º C)
Standards/ Ratings RoHS, UL 916, UL 924 (optional), FCC / IC / IFETEL
READ AND FOLLOW ALL SAFETY INSTRUCTIONS!
C US LISTED
TITLE 20/24
√
√ Verify that supply voltage is correct by comparing it with the
√ Make all electrical and grounded connections in accordance with
√ All wiring connections should be capped with UL approved
√ All unused connector openings must be capped.
https://nlight.acuitybrands.com/
OUTDOOR RATED
•
WHEN USING ELECTRICAL EQUIPMENT, BASIC SAFETY PRECAUTIONS SHOULD
•
•
•
Full warranty terms located at: www.acuitybrands.com/CustomerResources/Terms_and_conditions.aspx
WARNING - RISK OF ELECTRIC SHOCK
product information.
the National Electrical Code (NEC) and any applicable local code
requirements.
recognized wire connectors.
© 2020 Acuity Brands Lighting, Inc. All rights reserved. Rev. 11/16/2020
IMPORTANT SAFEGUARDS
ALWAYS BE FOLLOWED INCLUDING THE FOLLOWING:
DO NOT MOUNT NEAR GAS OR ELECTRIC HEATERS.
EQUIPMENT SHOULD BE MOUNTED IN LOCATIONS AND AT HEIGHTS WHERE
IT WILL NOT READILY BE SUBJECTED TO TAMPERING BY UNAUTHORIZED
PERSONNEL.
THE USE OF ACCESSORY EQUIPMENT NOT RECOMMENDED BY THE
MANUFACTURER MAY CAUSE AN UNSAFE CONDITION.
WARRANTY
5-year limited warranty.
WARNING - RISK OF BURN or FIRE
√ Do not exceed maximum wattage, ratings, or published
operation conditions of product.
√ Do not overload.
√ Follow all manufacturer's warnings, recommendations
and restrictions to ensure proper operation of product.
CAUTION - RISK OF INJURY
√ Wear gloves and safety glasses at all times when
installing, servicing or performing maintenance.
1 of 3
