Anland Security Technology
Installation and Operation Manual
Description: Keyless Knob Door Lock
Model No.: ES0001
Features: Fingerprint and PIN Code
Material: Zinc alloy furniture and SUS304 latch
Product Standard Referred: ANSI/BHMA A156.25
Thanks for choosing our premium quality product of smart home security with innovative design.
Please read this manual carefully before installation and use. For any query please contact us by email
customers-ast@anlandst.com
.
AST bids to the expert of creating value for customers in security and hardware!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ES0001 and is the answer not in the manual?

Questions and answers

Related Manuals for AST ES0001

Summary of Contents for AST ES0001

  • Page 1 Thanks for choosing our premium quality product of smart home security with innovative design. Please read this manual carefully before installation and use. For any query please contact us by email customers-ast@anlandst.com AST bids to the expert of creating value for customers in security and hardware!

  • Page 2: Table Of Contents

    Content 1. Parts Included in the Package ...............1 2. Product Configuration and Indication Light ...........1 3. Product Outline Dimensions ..............2 4. Cut-out of Door for Installation .............3 5. Installation of Latch Assembly and Strike Parts ........4 6. Installation of Interior and Exterior Knob Modules .......4 7.

  • Page 3: Parts Included In The Package

    1. Parts Included in the Package Tools in need but not included in the package: ① Phillips screwdriver; ② Tape measure 2. Product Configuration and Indication Light 2.1. A configuration of product and part’s description are as below image. 2.2. There are different indicating lights during setting and operating 2.2.1 Add Fingerprint The Fingerprint reader light turns to blue as to indicate the lock is ready to input new Fingerprint, please put your finger on the Fingerprint reader on Exterior Cover...

  • Page 4: Product Outline Dimensions

    Assembly. 2.2.2. Fingerprint identifying or mobile phone APP unlocking Green light: success (the buzzer beeps once, and the Fingerprint reader light flashes green.) Red light: failed (the buzzer beeps twice，the Fingerprint reader light flashes red.) 2.2.3. Low power of batteries When the lock is unlocked with Fingerprint or mobile APP, the buzzer beeps once and Fingerprint reader light flashes green and red.

  • Page 5: Cut-Out Of Door For Installation

    4. Cut-out of Door for Installation Please be noted that the Latch backset can be interchangeable (60mm/70mm)

  • Page 6: Installation Of Latch Assembly And Strike Parts

    5. Installation of Latch Assembly and Strike Parts Set the backset of Latch Assembly to 2.36” or 2.76” (60mm or 70mm) to fit your door hole as above image, then insert the Latch Assembly into the door hole, and drive screw A to fix the Latch Assembly, then install Strike Box and Strike Plate with screw A into the door frame.

  • Page 7: Installation Of Batteries (4 Ea Of Aaa, Non-Rechargeable)

    through the three holes of the Latch. Insert Interior Knob Module by aligning the two stems with the screw holes as above image, connect the cables by inserting the connector into the socket, and drive Screw B to fix Exterior and Interior Knob Modules. 7.

  • Page 8: Checking Of Function

    8. Checking of Function 8.1. After the Lockset is installed, please check the functions by Internal Snib as below image, to make sure the lock’s mechanism is working properly. 8.2. Wake up the Touchpad and input the right PIN code (inputting 6~8 digits and click “#”...
  • Page 9 8.4. Press the SET BUTTON on the rosette of Interior Knob Module for 8 seconds as above image, the buzzer will beep once and the Fingerprint reader will flash green. The lock will be reset to factory settings, then all the stored data will be wiped and new Fingerprint/PIN code will be required per the process of APP setting.

  • Page 10: Installation Of App And Settings

    key to check locking/unlocking function as above image. 9. Installation of APP and Settings 9.1. Download / Install the APP by mobile / IPAD Scan the below QR code to download the Tuya Smart APP, or search “Tuya Smart” in the APP Store (iOS) or Google Play (Android) to install the APP. 9.2.
  • Page 11 Choose the country where the Lockset will be used, enter your Email address to get verification code, set password, select permissions and press “Go to APP” to finish the registration as below images.
  • Page 12 9.3. Connect the Lockset to your APP Turn on the Bluetooth of your mobile phone, keep it close to the Lockset (within 5 meters as you will need to operate the Lockset though the Bluetooth can be working within 10~20 meters, anyway the actual Bluetooth working distance is subject to the circumstance and the Bluetooth of your mobile), then touch the Fingerprint reader to motivate the lock, and press the “Add Device”...
  • Page 13 9.4. Click “Add” and “+” to connect the Lockset you want to set up as below images...
  • Page 15 9.5. Press “ ”to rename the Lockset if you want. Now the Lockset is ready for use via APP.
  • Page 16 9.6. Control the Lockset via APP Click and drive the key icon “ ” from left to right “ ” position for unlocking the door as below images.
  • Page 17 9.7. Member management and Fingerprints / PIN Code input Select “Member Management” on the APP screen. Click “Me” and follow the APP instructions to add Fingerprint (similar to add the PIN Codes).
  • Page 20 Click “+” to add more PIN Codes of member. Important Note: Proper Fingerprint inputting is critical to access verification, most of the failures of Fingerprint identification are because of improper Fingerprint inputting, please make sure your finger is clean and positioned on Fingerprint reader precisely. 9.8.
  • Page 22 9.9. Setting Select “Settings” on the APP screen to turn on/off “Auto Lock” or set the time delay, or turn on/off “Do-Not-Disturb”.
  • Page 23 9.10. Device information setup Click the icon “ ” on the top right corner of the APP screen to check and set the relevant information...

  • Page 25: Technical Specifications

    11. Popular Questions and Answers Can ES0001 Lockset work with third-party parts like Latch Assembly? It is recommended to use the original parts for best performance and prem ium qual ity leve l .
  • Page 26 Tuya App, then try to connect again within a proper distance (like 10 meters) . If the connection between Lockset and APP is still not successful, please contact our customer service (customers-ast@anlandst.com) for technical support. What notification will I receive when the battery voltage is low? When you use F ingerprint or mobile APP to unlock, the LED Indicator will flashes green and red as a warning signal.

  • Page 27: Fcc Warning

    guaranteed as it is subject to the application circumstance and the Bluetooth of your mobile. The Lockset does not support the connection to other Smart Home System so far as such connection will need additional recognition and different encryption normally. 12.
  • Page 28 Anland Security Technology Revision: NR Language: English Size: A5 (14.8 X 21.0 cm) Remark: This document is property of Guangzhou Anland ST Co., Ltd and may be subject to change without notice. Made in China...
