Crest Audio ST1000 Specifications

(ST2000 model shown)
Power Specifications
1kHz, 0.1% THD+N
ST2000
ST1500
ST1000
Features
• Dramatically reduced net weight
• Switching power supply / switching output stages
• Very low current draw
• Latest generation of high-speed, wide-bandwidth output devices
• Cooled by variable speed fan with back-to-front airflow
• Inputs - Balanced female XLR, 1/4" TRS and three pin Phoenix
• Outputs - Speakon and five-way binding posts
• Mode selector switch for stereo, parallel and bridged-mono operation
• Ground-lift switch and rear panel circuit breaker
• Recessed, stepped attenuators with removable knobs
• 16-gauge steel chassis, 14-gauge steel front-panel
TourClass ® protection circuits
ACL (Active Clip Limiting) prevents speaker damage by providing
gentle gain reduction when signal approaches the clipping thresh-
old.
IGM (Instantaneous Gain Modulation) monitors speaker loads to
detect conditions that may overstress output devices. This allows
safe operation into nominal 2
AUTORAMP gradually increases gain to the attenuator level-set-
tings when the amplifier is turned on. This prevents abrupt turn-on
level.
Other protection features include: short circuit, dc voltage, com-
prehensive thermal management, current in-rush turn-on/off tran-
sient, and sub/ultrasonic input.
8Ω stereo 4Ω stereo
500w 1000w
400w 750w
280w 500w
speaker loads.
Ω
ST1000 - ST2000
Power Amplifiers
2Ω stereo
1200w
900w
650w
Description
The ST Series amplifier is the flagship in a family of elevated
efficiency amplification from Crest Audio. The ST amplifier
represents a new benchmark in switching amplification: pro-
viding the expected advantages of low-weight and reduced
heat, while preserving the sonic integrity for which Crest
Audio is known. With the latest in switching technology
onboard, this feature-rich product has the contemporary look,
feel and sound of a touring class amplifier. The ST Series is
competitively priced and is well suited for a wide range of
applications.
Resonant-switching power supply
The ST amplifier switching power supply employs a resonant
design which utilizes "zero-power" switching technology.
Benefits of resonant-switching include:
• Reduced power component stress for better reliability and
efficiency
• 20dB lower noise than conventional switching supplies (and
therefore more EMC friendly)
• Behaves like a classic linear supply, but with the added
advantages of minimized size and weight reduction
Switching output stage
To maintain sonic quality along with incorporating the advan-
tages of a switching output stage, Crest Audio's engineering
has two years of development time in this new generation
Class D amplifier. The multiple rail technology is the key to its
efficiency and low operating temperature. An additional
advantage to this design is the amount of power needed over
time. This amplifier will dramatically reduce the number of
kW/hr needed to operate.
S E R I E S
8Ω bridged 4Ωbridged
1750w 2400w
1500w 1800w
1000w 1300w
