Crest Audio MULTIPLEX 1100 Specifications

Multiplex 1100 power amplifier
description
The Crest Audio Multiplex 1100 integrates cost-effective
design with exceptional sonic accuracy, long-term reliability,
and the basic features required for cinema sound applica-
tions. The Multiplex 1100's remarkable price/performance
ratio is the result of innovative engineering and highly effi-
cient manufacturing in Crest's modern USA facility along
with nearly two decades of leadership in professional amplifi-
er design. The Multiplex 1100 offers a welcome balance of
exceptional audio performance and overall value. However,
no compromises in component selection or quality control
were permitted as a shortcut to cost reductions.
In every respect, the Multiplex 1100 embodies the Crest Audio
tradition of roadworthy ruggedness and reliability. For example,
the Multiplex 1100 includes the same TourClass protection fea-
tures as found in Crest's CA and CK Family amplifiers. The
Multiplex 1100 will endure virtually any type of mishap or sys-
tem stress – whether from uncontrolled upstream oscillation,
extreme ambient heat, or accidental shorting – without damage
to internal circuitry or connected speakers.
power specifications:
other Multiplex Series power amplifiers
4 stereo
Ω
1 , 0.01% THD+N
kHz
power specifications
1100
1 , 0.01% THD+N
kHz
Multiplex 900 Multiplex 1500
400w 750w
8 stereo
Ω
300w
features
robust "over-built" power supply – massive filter capacitors and
.
a high-output custom transformer provide ample current for solid
bass performance, even when driving low impedance loads.
more output transistors – by using more output devices than
.
comparable models, the Multiplex 1100 puts less stress on each device
yielding a wider safe operating area (
wide-band design – frequency response extends from 10
.
20 (-3 165
dB @
kHz
well as detailed, transparent high-frequency response.
more effective cooling – large, extruded aluminum heatsink and
.
front-mounted, two-speed 4-inch fan prolonging amplifier life by
minimizing internal temperatures.
front panel magnetic circuit-breaker/power switch
.
rear panel knobs attenuators (with cover)
.
differentially-balanced
.
five-way binding post or Speakon output connectors
.
(market dependent)
indicators –
LED
.
,
SIGNAL PRESENT CLIP
stereo/bridged-mono mode select switch
.
five-year warranty*
.
TourClass ® protection circuits
acl active clip limiting prevents speaker damage by
providing gentle gain reduction at the clipping threshold.
igm instantaneous gain modulation monitors speaker loads to
detect conditions that may overstress output devices, allowing safe
operation into difficult impedances.
autoramp gradually increases gain to the attenuator level-
settings when the amplifier is turned on.
Protection features include: thermal runaway,input overload, dc,
short circuit, in-rush current, and turn-on/turn-off transients.
4 stereo 8 bridged
Ω Ω
550w 1000w
) and long-term reliability.
SOA
), ensuring powerful sub-bass performance as
kHz
¼
-inch and Barrier Strip Input Connectors
TRS
, , and
ACTIVE PROTECT
Power figures are watts per channel, both channels driven.
to
Hz
