Trixie Valencia Assembling Instruction & Part List

Item No. Scratching Post
4377 Valencia
Pos. No. Description
Pos. 1 Bottom Plate with Cave
Pos. 2 Lying plate
Pos. 3 Lying plate with ball
Pos. 4 Post with spacer bolt
Pos. a Rounded head screw
Pos. b Washer
Pos. c Allen key
Pos. a
Pos. b
100118
Color Height
beige
28 in.
(71 cm)
brown
Measurement Quantity
17.25 × 5.75 × 12.75 in.
1
(44 × 25 × 33 cm)
11 × 11 in.
1
(28 × 28 cm)
11 × 11 in.
1
(28 × 28 cm)
ø 3.5 × 16.75 in.
2
(ø 9 × 43 cm)
M8 × 40 mm 2
M8 × 30 2
M5 1
 Advice: This product should be assembled by an adult.
TRIXIE Pet Products, Inc. · P.O. Box 101196 · Ft. Worth, TX 76185 · USA · www.trixiepet.com
Color Code
1
6
Item No. 1 Item No. 6
43776-10
43771-10
43771-11 43776-11
43776-12
43771-12
4377-30
-60
4377
Assembling Instruction & Parts List
4377
Item no.
