FORIOUS FF0220 Installation Instructions

You may need
1
1.Place Towel Ring on wall
where you need to install,
mark the outline of product
base with a pen.
5
5.Use allen wrench loosen
the setting screw and remove
the mounting bracket from
accessory.
2
2.Cover mounting bracket
paper on marked circle base,
mark 2 points according to
paper holes to drill wall holes.
6
6.Use screwdriver tighten
the mounting bracket on wall
stable.
INSTALLATION INSTRUCTIONS
3
3.Use 1/4 inch driller to drill
holes on wall which you
marked, the depth same as
white anchor.
7
7.Put the accessory onto
mounting bracket and tighten
the setting screw in bottom.
MODELS:FF0220
TOWEL RING
1.96 inch 2.55 inch
5.3 inch
6.3 inch
4
4.Use hammer hit the white
anchors into holes, make sure
who leanchor into hole.
8
8.Get the sturdy towel ring.
6.88 inch
