INSTALLATION INSTRUCTIONS
1
2
Included In the Package:
1. Faucet
2. Cold and hot water handles
3. Cold and hot water supply hoses
4. Black water hose with quick connectors
5. Rubber washer
6. Metal washer
7. Mounting nut
8. Mount screws
9. Pop-up sink drain stopper with mounting hardware
2
3
4
9
Before Installation:
• Turn off the water supply valves. Clean the mounting area of
the sink.
• Recommended width of mounting area is between 15cm-31cm
(6"-12") measured between centers of outside mount holes as
shown in the diagram.
• Diameter of mount holes must be between 32mm-35mm
(1.26"-1.38") as shown in the diagram.
• Max countertop thickness is 35mm (1.38")
• Water pressure Min 0.05MPa (7 psi) / Max 0.75MPa (109 psi)
• Water temp Min ≥ 20°C (68°F) / Max ≤ 85°C (185°F)
5
6
7
8
Advertisement
Related Manuals for FORIOUS FB-0300CH
Summary of Contents for FORIOUS FB-0300CH
- Page 1 INSTALLATION INSTRUCTIONS Included In the Package: Before Installation: 1. Faucet • Turn off the water supply valves. Clean the mounting area of the sink. 2. Cold and hot water handles • Recommended width of mounting area is between 15cm-31cm 3. Cold and hot water supply hoses (6”-12”) measured between centers of outside mount holes as 4.
- Page 2 Installation Steps: 2. Beneath the sink, 3. Tighten the 4. Insert the slide the rubber mounting nut by two mount screws washer, metal hand so that the 1. Feed hose through center mount onto the mounting washer and mount- faucet is firmly hole and fit the faucet onto the sink.
