WESTBRASS E531D-1F Instructions

E531D-1F
Instructions:
1. Remove existing spout. Clean threads on pipe with steel wool or wire
brush.
2. Make sure that pipe nipple extends 4-1/4 inches from wall face.
3. Using PTFE pipe tape on the male threads, install the new spout.
Note: When Installing, do not use lift rod for leverage, damage may result.
Tighten by hand only.
4. To operate, lift rod to activate shower.
Unthread
Desentrañar
Instrucciones:
acero o cepillo de alambre.
instalar la nueva canilla.
Precación: Al instalar la canilla, No Usar como apoyo el mango de levante ya
que podria dañar la unidad. Ajustar a mano únicamente.
4. Para accionar la canilla derivadora, levantar el mango para habilitar la ducha.
WESTBRASS
WESTBRASS
Fine Decorative Plumbing Since 1935
5-1/4"
1/2" FIP
3-1/2"
1/2" FIP
4-1/4 pulgadas
2-3/8"
1-1/2"
1"
WESTBRASS
Fine Decorative Plumbing Since 1935
Front Diverter Zinc Tub Spout
TITLE
DWG NO.
E531D-1F
NTS mrohlfs
Scale
E531D-1F
2429 E. Olympic Blvd.
Los Angeles, CA 90021
DATE REV
7-13-2012 B
Sheet 1 of 1
