- Page 1 2.5G/10G Series Ethernet Switch User Manual...
-
Page 3: Table Of Contents
Catalogue Chapter1ProductionIntroduction ⸻— 01 6Port,9Port2.5GSwitch......01 26Port2.5GSwitch........02 8Port10GSwitch........03 30Port2.5GPoESwitch ......04 Chapter2ProductInstallation ItemList ............05 InstallationSafetyPrecaution ....05 ..06 InstallationenvironmentPrecaution DesktopInstallation........07 ..........07 RackMount ⸻⸻— 08 Chapter3DeviceConnection NetworkConnection .........08 PowerConnection ........08 LoginManagement ........09 ⸻⸺ 10 Appendix:TechnicalParameter... -
Page 4: Chapter1ProductionIntroduction
Chapter1ProductionIntroduction 1.16Port,9port2.5Gswitchesfrontpanelisshowninthefollowingfigure: 5RJ45port Instructionlight 110GSFPport 8RJ45port Instuctionlight 110GSFPport ■ Working Indicator Name Operatinginstructions status Poweron Indicator Power indication light Poweroff Off Poweron 2.5Gbps (Green) Poweron 10/100/1000Mbps Link/Act Port (Yellow) (RJ45) status indicato Flashing Datatransmitting Off Linkfailure 1G/2.5G/10Gbps Link/Act Port (SFP) status Flashing Datatransmitting... -
Page 5: Port2.5GSwitch
1.226Port2.5Gswitchfrontpanelisshowninthefollowingfigure: 2.5GEthernetSwitch 135791113151719212325 2.5Gbps 10Gbps Port1-24 Port25-26 2.5Gbps 10/1001000Mbps VLAN(1-22) 2468101214161820222426 10G/2.5G Instructionlight Functiondialswitch 24RJ45port 210GSFPport ACINPUT100-240V Lightningprotectiongroundingscrew Powerinterface Indicator ■ Working Indicator Name Operatinginstructions status Poweron Power indication light Off Poweroff Poweron 2.5Gbps (Green) Poweron 10/100/1000Mbps Link/Act Port (Yellow) (RJ45) status indicator... -
Page 6: Port10GSwitch
1.38Port10Gswitchpanelisshowninthefollowingfigure: 10GEthernetSwitch Instuctionlight Eight10GRJ45ports Powerindicator ACINPUT100-240V Lightningprotectiongroundingscrew Powerinterface Indicator ■ Working Indicator Name Operatinginstructions status Power Poweron indication light Off Poweroff Poweron 2.5/5G/10Gbps (Green) Poweron 10/100/1000Mbps Link/Act Port (Yellow) (RJ45) status indicator Flashing Datatransmitting Poweroff Linkfailure... -
Page 7: Port2.5GPoeSwitch
1.430Port2.5GThePoEswitchpanelisshowninthefollowingfigure: 2.5GManaged P oESwitch 100M Link/Act 1000M/2.5G Alarm 1357911131517192123252729 Link/Act 24681012141618202224262830 Reset 10G/1G Instructionlight Resetbutton Consoleport 24RJ45port 610GSFPport Indicator ■ Working Indicator Name Operatinginstructions status Power Poweron indication Off Poweroff light System Systemstartupcompleted indicator Flashing Systemstarting light TotalPoEoutputpower≥80% PoEpower warning Off... -
Page 8: Chapter2ProductInstallation 2.1 ItemList
Chapter2ProductInstallation 2.1ItemList Switch Poweradapter(External Usermanual,certificateof switch) conformity 合格证 该产品经质量 检测合格， 准予出⼚ 检验员： 出⼚⽇期： ConsoleCable Rackear(Rackmount Powercord(Internal (Managementtype) switch) switch) 2.2InstallationSafetyPrecaution Duringinstallation,pleasewearanantistaticbraceletorgloves,andkeepthe ■ switchpoweredoff,toavoidpotentialsafetyhazards; Theswitchneedstobeatthecorrectvoltagetoworkproperly.Pleaseusethe ■ poweradapterprovidedwiththeswitchtopowertheswitch; Beforepoweringontheswitch,pleaseconfirmthatitwillnotcauseoverloadof ■ thepowercircuit,soasnottoaffectthenormaloperationoftheswitchoreven causeunnecessarydamage; Toreducetheriskofelectricshock,donotopenthecasingwhentheswitchis ■ working; Donotplaceotherheavyobjectsontheswitch,andkeeptheheatdissipation ■ holeoftheswitchwellventilated; Beforecleaningtheswitch,pleaseturnoffthepowersupplyanddonotuseany ■... -
Page 9: InstallationEnvironmentPrecaution
2.3InstallationEnvironmentPrecaution Temperature/Humidity Toensurethelong-termstableoperationoftheswitchandprolongtheservicelifeof theswitch,keeptheenvironmentatacertaintemperatureandhumidity.Toohighor toolowhumiditymaycauseelectricalleakageanddeformationofinsulation materials,orevencorrosionofmetalcomponents.Hightemperatureacceleratesthe agingprocessofinsulationmaterials,whichseriouslyaffectstheservicelifeof switches.Normaloperatingandstoragetemperature/humidityareshowninthe followingtable: EnvironmentalDescription Temperature Relativehumidity Workingenvironment -10℃〜50℃ 10%~90%RH,non-condensing Storageenvironment -40℃~70℃ 5%~95%RH,non-condensing Indoordustprevention Dustonthesurfaceoftheswitchcauseselectrostaticadsorption,whichprevents metalcontactsfromcontactingproperly.Althoughtheswitchtakescertain measurestopreventESD,whentheESDexceedsacertainintensity,itstillcauses fataldamagetotheelectroniccomponentsontheinternalcircuitboard.Toprevent ESDfromaffectingthenormaloperationofthedevice,pleasenotethefollowing: Regularlyremovedustandkeepindoorairclean; ■ ConfirmthattheequipmentiswellgroundedtoensuresmoothtransferofESD. ■ Electromagneticinterference Electromagneticinterferencecanaffectelectroniccomponentssuchascapacitors andinductorsinsidethedeviceinconductivewayssuchascapacitivecoupling, inductivecoupling,andimpedancecoupling.Inordertoreducetheadverseeffects causedbyelectromagneticinterferencefactors,pleasenotethefollowing: Thepowersupplysystemshalltakenecessarymeasuresagainstinterferenceof ■ thepowergrid; Theswitchshouldbefarawayfromhigh-frequencyhigh-power,high-current ■ devices,suchaswirelesstransmissionstations; Takeelectromagneticshieldingmeasuresifnecessary. ■... -
Page 10: DesktopInstallation
2.4DesktopInstallation DesktopInstallationDiagram Theswitchisinstalledonahorizontalworkbench,pleasenotethat： 1.Confirmthattheworkbenchisstableandfirm; 2.Maintaingoodindoorventilation; 3.Thedistancebetweenthepowersocketandtheswitchshallnotexceed1.2meters. 2.5RackMount M6 Screw FrameInstallationDiagram Thespecificinstallationstepsforinstallingtheswitchona19inchstandardrackare asfollows： 1.Checkthegroundingandstabilityoftherack; 2.InstallthetwoL-shapedbracketsintheaccessoriesonbothsidesoftheswitchpanel andfixthemwiththescrewsprovidedintheaccessories; 3.Placetheswitchinasuitablepositionwithintherack,supportedbyabracket; 4.FixtheL-shapedbracketonthefixedguidegroovesatbothendsoftherackwithM6 screwstoensureastableandhorizontalinstallationoftheswitchontherack. -
Page 11: Chapter3DeviceConnection
Chapter3DeviceConnection 3.1Networkconnections Afterpoweringon,pleasecheckthestatusofthecorrespondingindicatorlight. Ifthelightison,itindicatesthatthelinkisnormallyconnected,andifthelightis off,itindicatesthatthelinkisnotconnected.Pleasecheckthelinetoconfirm thatthepeerdeviceisenabled.Pleaserefertothecorrespondingpanel descriptionfordetailedindicatorlightdescriptions. 1.Whentheelectricalportuses2.5GEspeed,itisnecessarytouseCat5Eandabove networkcables. 2.Whenusing5GEspeedattheelectricalport,shieldednetworkcableswithCat5E andabovespecificationsarerequired,andunshieldednetworkcablesarenot recommended. 3.Whenusing10GEspeedattheelectricalport,itisnecessarytouseshielded networkcableswithCat6Aandabovespecifications. Attention： Whentheswitchisconnectedtoaworkstation,server,router,orotherEthernet ■ device,thenetworkcablelengthcannotbegreaterthan100meters; TheAutoMDI/MDIXfunctionoftheEthernetportoftheswitchisenabledby ■ default.;WhenCategory5twistedpaircablesareusedtoconnectEthernet, standardnetworkcablesorcrossnetworkcablescanbeused; DonotconnecttheRJ45porttoaphoneline; ■ 3.2Powerconnection 1.Checkthattheselectedpowersupplyisconsistentwiththepowersupply requirementsmarkedontheswitch; 2.Usetheoriginalpoweradapterorpowercordoftheswitchtoconnecttheswitch tothepoweroutlet. Ethernet Power... -
Page 12: LoginManagement
3.3LoginManagement WEBlogin Beforeloggingintothemanagementinterfaceoftheswitch,pleasesettheIP addressofthecomputerandtheIPaddressoftheswitchinthesamenetwork segment.ThedefaultIPaddressfortheswitchserviceportis192.168.2.1.Whena computerconnectstotheswitchserviceport,itisnecessarytosetthecomputerIP addressto192.168.2.x("x"isanyvaluebetween1-254,andcannotbe1),andthe subnetmaskto255.255.255.0. 1.ConnectthedeviceandPCtoensurethatthedeviceinitializationiscomplete. 2.ConfiguretheIPaddressofthePCtobeinthesamenetworksegmentasthe defaultIPaddressoftheswitch. 3.OpenthebrowseronthePCandenteritintheaddressbarhttps://192.168.2.1 "AfterpressingEnter,thewebmanagementlogininterfacewillbedisplayed.Enter thedefaultusernameadminandpasswordadmin,andpressEnterdirectly." Locallogin 1.UseaConsolecabletoconnectthePCtotheConsoleportoftheswitch. 2.OpentheterminalsimulationsoftwareonthePC,createanewconnection,and settheconnectionportandcommunicationparameters.Thecommunication parameterconfigurationofthePCterminalshouldbeconsistentwiththedefault configurationoftheswitchconsoleport.Thedefaultconfigurationoftheswitch consoleportisasfollows: Transmissionrate:115200 Databits:8 Verificationmethod::None Stopbit:1 Flowcontrolmode:None 3.PresstheEnterkeyuntilthesimulationterminaldisplaysthefollowingdisplay, promptingtheusertoenterausernameandpassword.Thedefaultusernamefor thefirstloginisadminandthepasswordisadmin. -
Page 13: Appendix:TechnicalParameter
Appendix:Technicalparameter IEEE802.3:EthernetMediaAccessControl(MAC)Protocol IEEE802.3i:10BASE-TEthernet IEEE802.3u:100BASE-XFastEthernet IEEE802.3ab:1000BASE-TGigabitEthernet IEEE802.3az:1000BASE-TGigabitEthernet(opticalfiber) Network IEEE802.3bz:2.5G/5GBASE-T5GEthernet Protocol IEEE802.3cb:2500BASE-XEthernet(fiberoptic) IEEE802.3an:10GBASE-TEthernet IEEE802.3ae:10GBASE-SR/LR10GEthernet(fiberoptic) IEEE802.3x:FlowControl IEEE802.3af; POEProtocol IEEE802.3at; IEEE802.3b FastEthernet100Mbpshalfduplex,200Mbpsfullduplex; Datatransfer GigabitEthernet2000Mpbsfullduplex; rate 2.5GEthernet5000MpbsFullDuplex; 10GEthernet20000Mpbsfullduplex. 10BASE-T:14881pps/port 100BASEX:148810pps/port Packet 1000BASE-T:1488095pps/port forwarding 2.5GBASE-T:3720238pps/port rate 10GBASE-T:14880952pps/port 10Base-T:2pairsofCat3oraboveUTP/STP(≤100m) 100Base-TX:2pairsofCat5orabovUTP/STP(≤100m) 1000Base-T:4pairsofCat5eoraboveUTP/STP(≤100m) 2.5GBASE-T:4pairsofCat5eoraboveUTP/STP(≤100m) 1000BASE-SX： 62.5μmMMF(Minimumrange:2m~275m)or50μmMMF NetworkMedia 1000BASE-LX： 62.5μm/50μmMMF(Minimumrange:2m~550m)or10μm SMF(Minimumrange:2m~5km) 2500BASE-X:G.652DSMF(Minimumrange:2m~500mor2m~5Km) 10GBASE-SR:OM1/OM2/OM3oraboveMMF(Operatingrange:2m~300m)
