Naomi Home Raelynn P-02911 Assembly Instructions

N A O M I
H O M E
PART LIST
1 - Sofa Base x1
2 - Left Armrest ×1
3 - Right Armrest ×1
4 - Sofa Back ×1
5 - Left Back Attachment ×1
6 - Right Back Attachment ×1
7 - Back Cushion ×3
8 - Seat Cushion ×3
9 - Leg ×4
®
Raelynn Button Tufted Sofa
1
2
A
9
A
9
A
Install 9(×2) into 2. Repeat for the same step to 3.
3
4
A
2
A
Slide 4 onto the brackets on the 2 and 3.
5
7
7
A
A
8
8
A
A
Put the 7(×3) and 8(×3) on the Sofa.
If you need help or have damaged or missing parts, contact customer service at
USE AND MAINTENANCE
- Use on level surfaces only
- Because this product needs assembly, it is prone to working itself
loose from time to time depending on the use. Please take the time to
check that all connections are still tight and working properly for safety.
- Only clean using a damp cloth and mild detergent, do not use bleach
or abrasive cleaners.
Assembly Instructions
2
3
A
9
A
9
A
4
3
A
7
A
8
A
Congratulations! Setup of your new
Naomi Home Raelynn Button Tufted Sofa is Complete!
Keep these instructions for future reference.
© 2022 Naomi Home, Inc. - All Rights Reserved.
2
A
1
A
Slide 2 onto the brackets on the 1. Repeat for 3.
5
A
4
A
Slide 5 onto the bracket on the 4. Repeat for 6.
www.NaomiHome.com
3
A
6
A
Made in China
