- Page 1 INSTRUCTION MANUAL...
-
Page 2: Assembly Guide
ASSEMBLY GUIDE Congratulations, you are now the owner of a brand new ergonomic chair! To best enjoy the comfort of the chair, you have to put it together first! This assembly guide will take you through the assembly process. To make sure the assembly goes well, please follow the instructions, and especially the important safety information. -
Page 3: Package List
Package List Without further ado, we kindly suggest you to list all parts needed for the chair first. (1)*1 (2)*1 (3)*2 Back Seat Armrests (4)*1 (5)*1 (6)*1 Mechanism Gas Lift Base (7)*5 (8)*5 (9)*4 Legs Casters Bolts (10)*8 (11)*10 (12)*8 Bolts Bolts protective Lid... -
Page 4: Assembly Instruction
Assembly Instruction Step 1: (11)×2 Turn the Base (6) upside down, and then insert the Legs (7) one by one to the Base. Use the Wrench (13) to screw Ten Bolts (11) into the pre-drilled screw holes to fix the Base and the Legs. - Page 5 Step 3: (9)×4 Align the Mechanism (4) over the pre-drilled holes underneath the Seat Cushion (2). Then fix it with the Bolts (9). ( Note: Don't make the direction wrong, make sure the front of the mechanism is facing the front of the Seat.
- Page 6 Step 5: Fix the Backrest (1) with Bolts (10), after make sure all of the bolts are tight fully, cover the screws hole with the Lids (12). (10) (12) (12) (10) 100% 100% CAUTION: Make sure all bolts and screws are fully tightened before using chair. Lubricate all moving parts and tighten all bolts/screws every 6 months or whenever needed.
- Page 7 Instructions For Use 1. Seat Height: Paddle-shaped lever on the right side To raise: While taking your weight off chair, lift lever up. To lower: While seated, lift lever up. * At the proper height, your feet should rest flat on the floor. 2.
- Page 8 3. Operating the tilt lockout To let your chair tilt back, pull the control handle out. To stop your chair from tilting, sit forward, then push the control handle in. 4. Armrests adjustment The armrest can be adjusted. Make it up and down if you need.
-
Page 9: Safety And Maintenance
Safety And Maintenance Do not stand on the chair, Do not use the chair as a stepladder. Use this product for seating one person at a time. Do not use the chair unless all bolts and screws are firmly secured. Avoid contact with sharp objects to prevent puncturing the fabric. -
Page 10: Limited Warranty
Limited Warranty The producer promises to repair or replace any chair that is found to be defective in material or workmanship within one (1) year from the date of original purchase so long as you, the original purchaser, still owns it. This is your sole and exclusive remedy. -
Page 11: Return Policy
RETURN POLICY： We adopt a 30 days return policy which means that all products purchased on this website may be returned to us within the timeframe. You need to contact us within 30 days after the product(s) came into your possession and the product(s) must be returned to us without any undue delays.
