FoMaKo KN30A-G Quick Start

Dear Friend,
Thanks for ordering FoMaKo cameras. To setup your streaming system easier, please read this quick start instruction first.
Video Out Methods:
(1) HDMI video output:
- HDMI port to HDMI TV/monitor, to preview video and change camera setting by press "menu" on remote control
- HDMI port to HDMI video switch/mixer
- Use HDMI to USB video capture card converting HDMI signal to USB signal, then, you can use this camera as a normal USB camera
(2) 3G-SDI Video output : 3G-SDI video out is similar as HDMI, the only difference is your device should support SDI .
(3) LAN Video output: Before using "LAN Video Out" , we should add the camera to your network.
(This camera comes with newest firmware with DHCP enable, network settings is much easier than cameras.)
How to find out camera's IP:
Method One:
Step 1: Camera LAN port -> Network Cable- > Router/switch (which your PC connected to)
Step 2: Download FoMaKo Camera IP Scanner tool and run it:
www.fomako.net/download/ip_search.exe ,
Step 3: Click "search", you can see camera's IP
Method Two:
Step 1: Camera HDMI port ->HDMI Cable->TV/monitor-> Camera's video come out on your screen
Step 2: Camera LAN port -> Network Cable- > Router/switch (which your PC connected to)
Step 3: Go to camera's menu by press "menu" button on remote control -> Network-> IP Addr.
you can see camera's IP address which assigned by your router. Please check the picture, this camera's IP is 192.168.0.100
Step 4: Turn "DHCP" to "OFF" , "whether to reset": YES,
Press "Home" button on remote control, the camera will reboot.
(Important: turn off DHCP, the camera will keep currently IP address, or when camera reboot, the IP address will be changed.)
Step 5: Now, you can login camera's webpage by camera's IP address: 192.168.0.100: we recommend to use Google Chrome.
username: admin password: admin
Add Camera to IP PTZ Controller:
Some information you need:
User Name: admin
We recommend to use IP Visca or Sony Visca control protocol, the two protocols are more steady and work better too.
Let's use FoMaKo KC-608 IP controller for example:
(1) Enable controller's DHCP: Setup button ->IP: Dhcp -> enter, controller will reboot.
Then, the router will assign an IP address to the controller
(2) Setup - >Add: IP Visca (or Sony Visca) -> input your camera's IP ->input port:5678 (sony visca:52381) ->input camera control ID(1-255 numbers)
(3) If you have more than one camera need to add to the controller, please press "IP" button to add the camera's IP address to controller one by one.
If you need more supports, please contact us at:
FoMaKo IP Streaming Camera Quick Start
Password: admin IP Visca port: 5678
ivan@fomako.net, normally, we can reply you within 12hours.
Sony Visca port: 52381 Onvif Port: 2000
FoMaKo Supports Team
