Apromise B0BB973NR2 Installation Instructions

Items included for glass without holes：
Glass panels
Brackets with set screws and silicone
washers and SUS304 plate and footpad
Items included for glass with holes：
Glass panels
Brackets with set screws and nuts and
SUS304 plate and footpad
Tools needed：
Phillips screw driver or other similar
screwdriver，outer hexagonal wrench
Instructions for Wind Guard without holes：
1. Carefully remove the panels from packaging and inspect
for any damage such as chips or cracks. Place glass panels upside
down on a soft flat surface to prevent any damage.
2. Loosen set screws in one of top bracket and slide two glass panels into brackets.
Ensure silicone pad is in place on tip of set screws and tighten a
little. Go on for the other three Top brackets in the same way.
3. Flip the sub-assembly up and install the bottom brackets in the same way,
then tighten all the screws when finished all the assembly.
4. Flip fully assembled wind guard over and place on the fire
pit and centralize around burner.
Instructions for Wind Guard with holes：
1. Almost the same assembly way as the wind guard without holes, but
just need to get all the screws through the holes and tighten by nuts.
Finally to tighten fully until all the brackets are assembled.
2. Flip fully assembled wind guard over and place on the fire
pit and centralize around burner.
Warnings：
Hot glass may cause burns.
Do not touch glass until cooled.
Never allow children to touch the glass.
Wind Guard Installation Instructions
(For Model:GL0007,GL0010)
Glass Panel without Holes
TM
Glass Panel with Holes
Glass
Panel
Top Bracket
Silicone Washer
Set Screw
Bottom Bracket
SUS304 Plate
Footpad
Screw
Glass Panel
Top Bracket
Set Screw
Nut
Bottom Bracket
SUS304 Plate
Footpad
Screw
