RunCam 5 Orange User Manual

RunCam 5 Orange
・Instruction Diagram
1
Shutter Button
2
Camera Status Light (LED)
3
Reset Button
Charging
Micro USB port supports DC 5-15V power supply. A DC 5V 1~2A charger is recommended.
Red LED
The will turn on during charging and turn off when charging is complete. It takes
about 2 hours to get fully charged.
Low Battery Warnings
When powered on, if the charge is less than 25%, the
seconds.
・Basic Camera Operation
Powering On/O
Mode Switch
Recording On/O
Parameter Settings
Forced Shutdown
Formatting
Reset
・microSD Card
Insert the microSD card as indicated by the icon next to the card slot.
Use brand name memory cards (sold separately)
that meet these requirements:
• microSD, microSDHC, or microSDXC
U3 recommended
•
requires U3 or above; other resolutions require
U1 or above)
• Capacity up to 128GB
NOTICE: Use carefully when handling memory cards. Avoid liquids, dust, and debris. As a precaution, power
off the camera before inserting or removing the card. Check manufacturer guidelines regarding use in
acceptable temperature ranges.
Abnormal SD Card Status: If the blue light continues to flash quickly after powering on, it indicates that
the SD card is not inserted, or full or cannot be recognized.
・Connection to Computer
After turning on the camera, connect it to the computer via USB cable, then it will be
recognized as a removable disc.
NOTICE: If the camera can not be recognized by the computer after connecting, please make sure that a
microSD card is well inserted. If the information on microSD card can not be read normally, please try with
another micro USB cable or USB port on the computer.
・Firmware Upgrade
To ensure that the camera performs optimally, please use the latest firmware.
Update method here: https://runcam.com/download/runcam5or.
・Video Bitrate and Codec
Resolution
4K@30fps
2.7K@60fps
2.7K@50fps
1440P@60fps
1080P@120fps
1080P@60fps
・Parameter
Image Sensor
Video Resolution
Field of View (FOV)
Video File Format
TV-OUT
Communication Interface
microSD Card supported
WiFi
Shutter
ISO
EIS Supported
USB Power Input
Battery Capacity
Power Consumption
Dimension
Net Weight
・Technical Support
Please visit: https://support.runcam.com
User Manual
• Long press the Shutter button with
the camera is under standby mode.
• Double-click the Shutter button to cycle through the
recording mode
• In the recording mode, click the Shutter button to start
recording, the green light flashes; click the Shutter button
again, the recording stops, the green light stops flashing.
• Set in the RunCam App
• Simultaneously press the Shutter button and
Reset button.
• In standby mode. Triple-click the Reset button,
with a long beep and
• In standby mode. Long press the Reset button,
with three beeps and
(2.7K50/2.7K60 1080P120
Video Quality
High
60Mbps
60Mbps
60Mbps
40Mbps
60Mbps
45Mbps
SONY IMX 377 (12MP)
4K@30fps/2.7K@60fps/2.7K@50fps/
1080P@120fps/1080P@60fps/1440P@60fps
145°
MP4
Support
Micro USB
Up to 128G.
U3 recommended (2.7K50/2.7K60 1080P120 requires
U3 or above; other solutions require U1 or above)
Please make sure that the file format of the SD card is
FAT32, otherwise, it will easily cause errors.
Nonsupport
Auto 1/30 1/60 1/120 1/240
Auto/100/200/400/800/1600/3200
Only e ective at 4K@30fps, 1080P@60fps for now
DC 5-15V
900mAh
Max 620mA @5V
38*38*36mm
56g (with battery)
1
2
3
4
5
6
4
SD Card Slot
5
SD Card Locking Door
6
Micro USB Port
Blue LED
LED), setting mode
(Green
Green LED
blinks three times.
Blue LED
blinks three times.
Medium
50Mbps 40Mbps
50Mbps 40Mbps
50Mbps 40Mbps
30Mbps 20Mbps
50Mbps 40Mbps
30Mbps 22Mbps
will continue to flash for 3
Green LED
on,
LED)
(Blue
Codec
Low
H.264
