RunCam Scope cam 2 User Manual

Instruction Diagram
Charging:
Type-C only supports DC 5V power supply, please use conventional phone charger or power bank.
Green light will turn on during charging, while it will tun off when it is fully charged.It takes about 2
hours to get fully charged.
Low Battey Reminder:
When the battery is lower than 8%, the camera vibrates 4 times continuously, 30s each vibration.
MicroSD Card
Capacity up to 128GB; High Speed SD card (Class 10/UHS-I/UHS-II/UHS-III )is highly recommended
Note: The camera only supports FAT32 or exFAT format, SD cards over 64GB must be formatted via the App.
Basic Camera Operation
Start Recording
Stop Recording
Open WIFI
Close WIFI
Forced shutdown
Abnormal Status
Connection to the Computer
U Disk Mode:
Connecting to PC via TYPE-C to USB, the camera will enter into U disk mode automatically, recording
indicator(red light） is on
WEBCAM/PCCAM/UVC Mode
Short pressing WIFI button to switch to WEBCAM/PCCAM/UVC mode in U disk mode, then Short
pressing WIFI button can switch back and forth to U Disk or WEBCAM mode.
NOTICE: If the camera cannot be recognized after connecting to the computer, please confirm whether there is microSD card in Scope cam 2.
If the information in the SD card cannot be read normally, please replace the USB cable or retry the computer USB port.
1. Long press WiFi button 3s, LED1(blue light) flashes, WiFi is started and waiting for connection.
2. Find the SSID connection of the Scope Cam 2 in the wireless network of the mobile phone and
enter the password, after successful connection, firmware update/WIFI indicator（blue light) is
constantly on
3. Default SSID: RCSC02_*****PW:1234567890
Android and iOS APP: Search 'RunCam App' on Google Play/App Store, or download on our website:
https://runcam.com/download/scopecam2.
Firmware Upgrade
Firmware Upgrade Status (Blue light blinks)Ensure that the Scope Cam battery is more than 50%
before the upgrade.
Manually copy the firmware file (FWSCLITE.bin) onto the microSD card. Follow the instruction on
https://runcam.com/download/scopecam2.
To get the latest features and best performance from your Scope Cam, make sure you are using the
most current camera software. You can update your firmware with the RunCam App or at
https://runcam.com/download/scopecam2.
Parameter
Image Sensor
Lens
ISO
Shutter
Resolution
Video format
Memory Card
File system
Battery
Battery life
Charging time
Wi-Fi
USB Interface
Work Current
Work Temp
Housing Material
Vibration motor
Waterproof
Mount
Net Weight
Dimensions
Technical Support
Please visit: https://support.runcam.com/hc/en-us
Scope cam 2 User Manual
Push button up,
LED1, LED2(Red Light) have a slow flash at 1s interval simultaneously
Push button down,
LED1 and LED2(Red Light) turn off simultaneously
Operation1: Long Pressing WIFI button 3s in recording status
Waiting for a connection: LED1( Blue light flashes slowly at 1s interval),
Connected: LED1(Blue Light is on)
Operation2: Long Pressing WIFI button 3s in shutdown status
Waiting for a connection: LED1( Blue light flashes slowly at 1s interval)
Connected: LED1(Blue Light is on)
Long pressing WIFI button 3s,
LED1 (Blue light) off, the camera turns off simultaneously
Long pressing WIFI button 8s
No SD card or SD card abnormality, LED1,
LED2 have a quick flash simultaneously
1/2.9"CMOS 2MP
40mm@FOV 8.2
100 / 200 / 400 / 800 / 1600
1~1/500s
1080P@60fps / 1080P@50fps / 720P@90fps
MP4(H.264)
Micro SD(Max 128g)
Fat32/exFat
1400mAh
About 240 minutes (1080P@60fps)
About 120 minutes
2.4g
Type-C
1.25W (wi-fi off)
-10°C ~ 45°C
Aluminum alloy & PA
Built-in
IP64
Picatinny
40mm@135g
112mm*32mm*36mm
WiFi Button
Powering on /off Switch
LED1 Red Light（Recording Status）/ Blue Light(WiFi Status)
LED2 Red Light( Recording Status)/ Green Light (Charging Status)
Micro-SD Card Slot
Type-C
MICROPHONE
25mm@FOV 12°
25mm@130g
93mm*32mm*36mm
3.6mm@FOV 126
3.6mm@118g
79mm*32mm*36mm
