PLATE COMPACTORS
Start-up Guide
ONLY USE 4 stroke petrol.
fuel cap and fill the fuel tank with 4
stroke petrol. Replace fuel cap. Wipe
clean any spillages.
Move the throttle lever up 1/2
clicks towards the fast position.
Allow the engine to warm up for 2
minutes. Then move the choke lever all
the way to right/RUN.
Caution:
Do not leave unattended while
the engine warms.
Unscrew
Unscrew the oil fill plug and fill the oil
tank with SAE-10W-30 multi viscosity
oil. Replace oil fill plug. Wipe clean any
spillages.
Turn the engine ON/OFF switch to the
ON position.
Increase the throttle lever setting to
obtained desired speed. Lower throttle
setting will produce a lower lever of
compaction. High throttle settings
produce harder compaction.
Pull the choke to left/START position
to close the choke and pull the fuel
lever to the right/RUN position.
NOTE:
If the engine is still hot,closing
the choke is not necessary.
Pull the recoil starter hard until the
engine starts. Once started, reduce
the throttle lever 1/2 clicks back to
lowest setting.
To stop the unit, set the throttle lever to
lowest setting and turn the engine
on/off switch to the OFF position.
Finally, push the fuel lever to the left/
closed position.
