Universal Remote Control INSIGHT M1057 Manual

Comcast OnDemand Mnl M2057.qxd
ON DEMAND FEATURES AND FUNCTIONS
Custom 3-Device
Use the remote control' s mode keys
(i.e., AUX, TV, or Cable) to control a spe-
Universal Remote Control
cific device. When pressed, the selected
mode key will light, confirming your
choice. Use the other keys to perform
desired actions (see the following key
chart).
NOTE: The selected mode will remain active
until you press another mode key.
Press AUX, TV, or Cable
once to select and
control a device.
Press Power once to
turn on or off the
selected home enter-
tainment device.
Use Setup for all
programming
sequences.
Press All On once to
turn on or off all
programmed devices
in this order: Cable,
TV, and AUX. After all
devices are on, Cable
is the active mode.
Press ON DEMAND once
to access the available
ON DEMAND menu.
In the AUX or TV
USERS GUIDE
mode, use the
transport keys to
control a VCR, PVR,
or DVD player. To
OVERVIEW
record a program on a
VCR, press REC twice.
The ON DEMAND Custom 3-Device
In the Cable mode, use
Universal Remote Control will control
up to three home entertainment devices, the keys to control ON
DEMAND programs.
including a Cable Box (used by your
cable system), a TV, a VCR, an Audio
Use A, B, or C to access
Amplifier or Receiver, a DVD player, or a
interactive program
PVR.
guide functions on
your Scientific Atlanta
The remote control requires installing
Explorer, Pioneer
two (2) new AA batteries (included)
Voyager, or Pace Cable
and some easy programming to
Box.
control your devices. For best results,
please read and perform all
Use Lock to restrict
instructions listed here. Also, keep this
viewing of selected
guide for future reference.
programs (Parental
Control) on your
Motorola (GI or
INSTALLING BATTERIES
Jerrold) Cable Box.
Use PPV to access
1. Pull back the remote control' s
battery cover and remove it. information on avail-
able Pay-Per-View
2. Insert the two (2) supplied
movies and events on
AA batteries according to the +
your Motorola (GI or
and - marks in the battery case.
Jerrold) Cable Box.
3. Push the battery cover back
Use Page+ (or Page-)
into place.
to page up (or down)
through menu screens
4. Test the unit by pressing any
and the interactive
mode key (i.e., AUX, TV, or Cable).
If batteries are inserted correctly, program guide.
the selected mode key will light.
Use Guide to display
the interactive
NOTE: When batteries need replacement,
program guide.
the remote control will stop operating.
Replace the old batteries and the unit will be
restored to its full functionality, complete
with your favorite settings.
10/5/2004 11:58 AM Page 1
Use these keys to move PROGRAMMING
the cursor in the inter-
DEVICE CONTROL
active program guide
and menu screens. The ON DEMAND Custom 3-Device
Universal Remote Control is prepro-
Use OK (Select)to select
grammed at the factory to operate the
menu options, PPV
Cable Box supplied by your cable
events, and programs
system, an RCA TV, and an RCA VCR
from the interactive
(in the AUX mode). To control devices
program guide.
other than default brands (excluding the
Cable Box), perform the below steps;
Use Info to display
otherwise skip this section:
current channel and
program information.
1. Turn on a device (e.g., VCR or
DVD Player) and, if applicable,
Use Menu to display
insert media, (e.g., video cassette
the Quick Menu (on a
Motorola, GI, or or disc).
Jerrold Cable Box), or
NOTE: Please read steps 2 to 6 com-
to access settings (on a
pletely before proceeding. Highlight or
Scientific Atlanta
write down the codes and device you
Explorer, Pioneer
wish to program before moving on to
Voyager, or
step 2.
Pace Cable Box).
2. On the remote control, press a
Use Exit to exit the
device key once (i.e., AUX or TV).
menu or guide.
NOTE: Use the AUX key to program
Use Help to access the
control of an Audio Amplifier or
digital cable help.
Receiver, a DVD Player, a Home-
Use Last to recall the Theater-In-A-Box Device, a PVR (or
last channel or go back DVR), or a VCR.
one screen in the
3. Press and hold Setup until the
menu.
selected mode key blinks twice,
then release Setup.
Use VOL+ (or VOL-)
to raise (or lower) the
4. Locate the code for your device in
sound volume. Also
Manufacturer' s Codes on the back
see Changing Volume
of this user guide. Brands are list-
Lock.
ed in alphabetical order with the
most popular codes listed first.
Press Mute once to
turn sound off or on.
5. Enter the first four-digit code for
your device. If you perform this
In the Cable mode,
procedure correctly, the selected
press FAV once to
mode key will blink twice.
display programmed
favorite cable chan-
NOTE: If you enter an invalid code,
nels.
the selected mode key will display one
Use CH+ (or CH-) to long blink and exit the programming
select the next higher mode. Repeat steps 2 to 5 with a valid
code.
(or lower) channel.
6. Aim the remote control at your
When controlling a
device and press Power once. The
DVD player, use CH+
device should turn off. If it does
(or CH-) to skip
not respond, repeat steps 2 to 6,
forward (or skip
trying each code listed for your
reverse) through
brand until you find one that
video.
works. If it still does not work, try
Use the keypad (0 ~ 9)
Searching For Your Code.
to directly select the
channels (e.g., 9 or NOTE: If the device does not have a
31). Power key, press the
7. For future reference, write your
In the TV mode, use device code in the appropriate
boxes below:
this key to switch the
TV' s input to view TV
AUX Code:
or video programs.
In the AUX mode, use
this key to switch the
VCR, PVR (or DVR),
Device Type:______________
or DVD player to view
TV or video. For an
TV Code:
audio device, use it to
switch to an input
source.
Use Enter to enter
8. Repeat steps 1 to 7 for another
channels on some TV
device you want to control.
models or information
on menu screens.
6. To check another device code,
SEARCHING FOR YOUR CODE
repeat steps 1 to 5, but substitute
If your home entertainment device does the AUX key for the auxiliary
not respond to the remote control after
device you are checking. Write
trying all the codes listed for your brand,
down the codes in the appropriate
or if your brand is not listed at all, try boxes below:
searching for your code.
AUX Code:
For example, if, after trying all of the
codes for your TV, you still cannot get
the remote control to operate your TV,
then:
Device Type:______________
1. Turn on your TV.
TV Code:
2. On the remote control, press TV
once. Then press and hold Setup
until the TV key blinks twice, then
release Setup.
3. Enter 9 - 9 - 1. The TV key will
blink twice. CHANGING VOLUME LOCK
4. Aim the remote control at the the
The ON DEMAND Custom 3-Device
TV and slowly alternate between
Universal Remote Control is set at the
pressing Power and TV.
factory to control the TV volume in all
modes.
Stop when the TV turns off. A
working code has been found.
However, you may change the Volume
Lock setting to Individual Volume
NOTE: In the search mode, the
Unlock to unlock a specific device' s vol-
remote control will send IR codes
ume controls for independent opera-
from its library to the selected device,
tion in its own mode (e.g., Audio
starting with the most popular code
Receiver volume controls in the AUX
first.
mode).
5. Press Setup once to lock in the
Or, if desired, you can perform Global
code. The TV key will blink twice.
Volume Unlock so that the volume
6. To search for the codes of another
controls of all devices can be indepen-
device, repeat steps 1 to 5, but
dently operated in their own modes.
substitute the AUX key for the aux-
iliary device you are searching for. Unlocking Volume Control For A
Single Device (Individual Volume
Unlock):
CHECKING THE CODES
1. Press a desired mode key where
you want volume to be unlocked
If you have set up the remote control
(e.g., AUX) and controlled within
using the Searching For Your Code
its own mode.
procedure, you may need to find out
which four-digit code is operating your
2. Press and hold Setup until the
equipment. Perform the following steps
selected mode key blinks twice,
after setting up your devices to find out
then release Setup.
which four-digit code operates your
equipment. For example, to find out 3. Enter 9 - 9 - 3 and then press VOL-
which code is operating your TV: once. The mode key will blink
four times, confirming unlock.
1. Turn on your TV.
4. If desired, repeat steps 1 to 3 (of
2. On the remote control, press TV
this section) for each device that
once. Then press and hold Setup
you want volume to be unlocked.
until the TV key blinks twice, then
release Setup. 5. Now, after you select a device that
has volume unlocked (e.g., AUX),
3. Enter 9 - 9 - 0. The TV key will
pressing VOL+, VOL-, or Mute, will
blink twice.
(Play) key.
control the device' s volume only
in its own mode.
4. To view the code for the first digit,
press 1 once. Wait 3 seconds and
Unlocking All Volume Controls
count the number of times the TV
(Global Volume Unlock):
key blinks (e.g., 3 blinks = 3) and
write down the number in the
1. Press and hold Setup until the
leftmost TV Code box (at end of
selected mode key blinks twice,
this section).
then release Setup.
NOTE: If a code digit is "0", the select-
2. Enter 9 - 9 - 3 and then press
ed mode key will not blink.
VOL+ once. The mode key will
blink four times, confirming
5. Repeat step 4 three more times for
unlock.
the remaining digits. Use 2 for the
second digit, 3 for the third digit,
3. Now, volume controls for all
and 4 for the fourth digit. Finish
devices can be independently
writing down the code in the TV
controlled in their own modes.
Code boxes (at end of this sec-
tion).
Locking Volume Control To TV or Re-Activating Channel Control Lock
AUX Mode:
1. On the remote control, press
Cable once. Then press and hold
1. Press and hold SETUP until the
Setup until the Cable key blinks
Red light flashes twice, then
twice, then release Setup.
release SETUP.
2. Enter 9 - 7 - 3. Press CH+ once.
2. Enter 9 - 9 - 3 (Red light will flash
twice). The Cable key will blink twice.
3. Press and release either TV or AUX 3. Now, regardless of whether you
(Red light for selected device will select the TV or Cable mode, only
flash twice).
the channel control capability of
your cable box will be accessible.
REASSIGNING DEVICE KEYS
TROUBLESHOOTING
The ON DEMAND Custom 3-Device
Universal Remote Control can be set up PROBLEM: A mode key does not
to control a second device. blink when you press
a key.
For example, to have the unit control a
TV, a Cable Box, and second TV, you SOLUTION: Replace the batteries with
will need to reassign the unused AUX two (2) new AA batteries.
key to operate the second TV as
PROBLEM: During programming, a
follows:
mode key displays one
1. On the remote control, press AUX
long blink.
once. Then press and hold Setup
SOLUTION: An invalid entry has
until the AUX key blinks twice,
occurred. Check the key
then release Setup.
to be entered and try
2. Enter 9 - 9 - 2. The AUX key will programming again.
blink twice.
PROBLEM: A mode key blinks when
3. Press TV once, then press AUX
you press a key, but the
once. The AUX key will blink home entertainment
twice. component does not
respond.
4. The AUX key is now ready to be
programmed for your second TV. SOLUTION: Make sure the remote
See Programming Device Control
control is aimed at your
for instructions. home entertainment
device and is not farther
than 15 feet away.
PROGRAMMING CHANNEL
PROBLEM: The remote control does
CONTROL LOCK not control home enter-
tainment devices or the
By default, the remote control' s
commands are not work-
channel-control capabilities are locked
ing properly.
to the Cable Box. The affected keys are
SOLUTION: Try all listed codes for
0 ~ 9, CH+, CH-, Enter, and Last.
the device brands being
This will guarantee that you do not
set up. Make sure they
inadvertently change a channel while in
can be operated with an
the TV mode. However, you can turn
infrared remote control.
off this feature to allow full access to
PROBLEM: PLAY and STOP do not
these keys in the TV and Cable modes.
work on a Motorola
NOTE: This feature does not affect the AUX
DCT-2000 cable convert-
mode.
er [HS1].
De-Activating Channel Control Lock SOLUTION: Re-program the CBL key
for cable code 0476 (see
1. On the remote control, press
Programming Device
Cable once. Then press and hold
Control).
Setup until the Cable key blinks
twice, then release Setup. PROBLEM: Changing channels does
not work properly.
2. Enter 9 - 7 - 3. Press CH- once.
The Cable key will blink four SOLUTION: If original remote control
times. required pressing Enter
to change channels, also
3. Now, the remote control will
press Enter on this
provide TV or cable channel
remote control after
control capabilities while in the
entering the channel
TV or Cable mode.
number.
